RF Connector

Product Image (3AN-002-0039)

TNC Connector Panel Mount 4Hole Flange RP Jack For Cable UT085

Price: 85 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+165oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0005)

UHF Connector Panel Mount Straight 4Hole Flange SO 239 For Cable

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0050)

UHF Crimp Connectors Female Crimp Type With Knurl For Cable

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0037)

UHF Crimp Connectors Male Right Angled With For Cable

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0041)

UHF Female Connector Solder Type 2 Hole For Flange Mount

Price: 75 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0015)

UHF Connectors PL 259 Plug Straight For Cable

Price: 50 INR/Piece

Description: Cable Connector, plug/male, Straight/180, Solder Type Features: Cable Connector, plug/male, Straight/180, Solder Type; Designed for low frequency systems from 0.6-300MHz; Threaded coupling mechanism is easy for assembly with high durability; From the OEM Original Factory, same quality with much better price. Main Application of UHF Connectors: Antennas, Military, Public Address Systems and Low-frequency applications

Product Image (3AN-009-0011)

LMR 600 UHF Connector PL259 Male Clamp Type For LMR300 LMR600

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0009)

Right Angle UHF Connector PL 259 Plug Crimp Type For RG214, LMR195

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0022)

UHF Female Connector Straight 4 Hole Flange Clamp Type For Cable

Price: 120 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0025)

UHF Female Flange Mount Straight Connector For Rear Bulkhead

Price: 120 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0033)

UHF Jack Front Bulkhead Connector R/A Crimp Type For Cable

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0023)

UHF Male Coaxial Connector Straight Clamp Type For Cable

Price: 65 INR/Piece

ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0001)

TNC Male Connector RG58 Straight Solder Type For Cable RG59

Price: 85 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~1Ghz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0091)

TNC Plug Crimp Straight 50 Cable Mount Male Termination For LMR400

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0100)

TNC Plug Male Straight 50 Cable Mount TNC Plug Crimp Termination For RG174

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0071)

TNC Plug Male Straight 50 Rg58 Clamp For Cable

Price: 55 INR/Piece

Description: Plug,TNC,Male,Straight,RG58,Clamp,for Cable,Teflon,50ohm,75ohm,Brass,Nickel Features: Plug,TNC,Male,Straight,RG58,Clamp,for Cable,Teflon,50ohm,75ohm,Brass,Nickel ; Thread Version of BNC used in Vibration-Intense application with high durability; Higher Performance than BNC with 0-11 GHz Microwave frequencies and 50 ohm impedance; From the OEM Original Factory, same quality with much better price. Main Application of TNC Connectors: Cellular Mobile Phones, Aviation Controls, Telemetry, Bluetooth and GPS, Wireless Base Station, Microwave Comonents, Radar, Networks,Antenna Mounts, Machine to machine communications, Security Devices, Instrumentation.

Product Image (3AN-002-0034)

TNC Plug Right Angled RP Crimp Type For Cable RG316

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+165oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0097)

TNC Plug Straight 50 Cable Male Mount Solder Termination For RG58/U

Price: 50 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0085)

TNC Straight 50 Cable Mount Male Plug Crimp Termination For RG58C

Price: 45 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0001)

UHF Female Connector Straight Bulkhead For Panel Mount

Price: 85 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C +149C Copolymer of styrene and polystyrene: -55C +85C TFE insulators: -65C +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0048)

UHF Connector Jack Straight Clamp Type For Flange Mount

Price: 75 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C +149C Copolymer of styrene and polystyrene: -55C +85C TFE insulators: -65C +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0018)

UHF Male Connector Straight Gold Plated Crimp Type For Cable

Price: 55 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0048)

UHF Connector Jack Straight Clamp Type For Flange Mount

Price: 55 INR/Piece

Description: UHF Connector, Female, 4 Hole Flange, Straight/180, Panel Mount,UHF-SL16-KF5 Features: UHF Connector, Female, 4 Hole Flange, Straight/180, Panel Mount,UHF-SL16-KF5; Designed for low frequency systems from 0.6-300MHz; Threaded coupling mechanism is easy for assembly with high durability; From the OEM Original Factory, same quality with much better price. Appliance: Antennas, Military, Public Address Systems and Low-frequency applications Electrical Characteristics ImpedanceNon-constant Frequency Range: 0300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact)

Product Image ( 3AN TELECOM)

RP TNC Plug Connector Straight Crimp Type For RG58/RG174

Price: 40 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0001)

UHF Female Connector Straight Bulkhead For Panel Mount

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C +149C Copolymer of styrene and polystyrene: -55C +85C TFE insulators: -65C +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0019)

UHF Female Connector Front Bulkhead For Panel Mount

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C +149C Copolymer of styrene and polystyrene: -55C +85C TFE insulators: -65C +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0004)

TNC Male Crimp Connector RG6 Angled For Cable

Price: 85 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~1Ghz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0034)

UHF Female Connector Front Bulkhead For Panel Mount

Price: 55 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C +149C Copolymer of styrene and polystyrene: -55C +85C TFE insulators: -65C +165C Weatherproof: Except as noted, all UHF series are non-weatherproof Material:

Product Image (3AN-009-0004)

Straight UHF Connector Jack Crimp Type For LMR195

Price: nan INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0031)

UHF Male Crimp Type With For Cable Connector

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image ( 3AN TELECOM)

UHF Bulkhead Female Angled Solder Type For Panel Mount

Price: 75 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0086)

TNC Male 50 Ohm RF Coaxial Straight Plug Clamp Termination For Cable

Price: 35 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204

Product Image (3AN-002-0087)

TNC Female Straight Panel Mount Connector Crimp Termination For RG174/U

Price: 45 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0109)

TNC Connector Crimp Straight Male 50 Cable Mount Termination Reverse Polarity

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 011 GHz for 50 ohm VSWR: Straight type ‰ 1.3max / R/A type ‰ 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance ‰ 3.0 mÎ (Milliohms max.) Outer Contact Resistance ‰ 2.0 mÎ (Milliohms max.) Insultation Resistance ‰5 — 10 ³ mÎ (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: ‰500 cycles Environmental Characteristics Environmental Characteristics: -65oC+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0109)

TNC Connector Crimp Straight Male 50 Cable Mount Termination Reverse Polarity

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 011 GHz for 50 ohm VSWR: Straight type ‰ 1.3max / R/A type ‰ 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance ‰ 3.0 mÎ (Milliohms max.) Outer Contact Resistance ‰ 2.0 mÎ (Milliohms max.) Insultation Resistance ‰5 — 10 ³ mÎ (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: ‰500 cycles Environmental Characteristics Environmental Characteristics: -65oC+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0075)

TNC Female Plug Straight Crimped For Cable RG58

Price: 35 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-1245-125)

TNC Connector Sraight Bulkhead Female Solder Type

Price: 30 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+165oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0021)

UHF Cable Female Connector Coaxial With Clamp Type

Price: 75 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0010)

UHF Clamp Connector Straight Female For Cable

Price: 55 INR/Piece

Main Application of UHF Connectors: Antennas, Military, Public Address Systems and Low-frequency applications Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0081)

TNC Male Plug Straight 50 Soldering Clamp For Cable

Price: 45 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0007)

TNC Connector Female Straight Bulkhead For Front Panel Mount

Price: 35 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~3 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0032)

TNC Connector Right Angle Male Crimp Type For Cable RG316

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+165oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0111)

TNC Connector Male Straight 50 Cable Mount Crimp Termination For RG58

Price: 55 INR/Piece

Description:Male, Straight,Crimp,Cable,Mount,Nickel,50,Brass,RG58 Features: Male, Straight,Crimp,Cable,Mount,Nickel,50,Brass,RG58; Thread Version of BNC used in Vibration-Intense application with high durability; Higher Performance than BNC with 0-11 GHz Microwave frequencies and 50 ohm impedance; made according to MIL-C-39012 standard;; From the OEM Original Factory, same quality with much better price. Main Application of TNC Connectors: Cellular Mobile Phones, Aviation Controls, Telemetry, Bluetooth and GPS, Wireless Base Station, Microwave Comonents, Radar, Networks,Antenna Mounts, Machine to machine communications, Security Devices, Instrumentation

Product Image (3AN-002-0035)

TNC Connector Male Right Angle Crimp Type For Cable RG142,400

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -55oC~+155oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0112)

TNC Connector For RG140/U Male Straight 75 Cable Mount

Price: 35 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0089)

TNC Connector Clamp Straight Male Standard 50 Cable Mount Termination

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0027)

UHF Male Connector Gold Plated Crimp Type For Cable

Price: 55 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0009)

TNC Connector Bulkhead Female Straight Crimp Type For Cable

Price: 5 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~1Ghz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0099)

TNC Connector 4 Hole Flange Female Straight 50 Panel Mount Bulkhead Fitting Solder Termination

Price: 65 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0008)

TNC Bulkhead Connector Crimp Type Straight For Panel Mount

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~3 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-1245-26)

RP-TNC Plug Connector Straight Crimp Type For Cable RG316

Price: 40 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -65oC~+165oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image ( 3AN TELECOM)

UHF Male Coaxial Connector Sliver Plated Crimp Type For CableMale Coaxial Connector Sliver Plated Crimp Type For Cable

Price: 55 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0038)

TNC Bulkhead Connector Straight Jack Panel Seal For Cable

Price: 95 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+125oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0049)

UHF Connector Flange Mount Female 4 Hole For Panel Mount

Price: 75 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0006)

UHF Panel Connector SO 239 4Hole Flange For Mount

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0073)

TNC Male Angled Rg58 Crimped For Cable

Price: 75 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0079)

TNC Plug Straight Screw Terminal For Cable RG58

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0067)

TNC Male Connector Right Angle Crimp Type With LMR240

Price: 75 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0010)

TNC Connector PCB Mount Right Angled Bulkhead Female

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0003)

TNC Connectors For RG6 Straiht Plug Crimp Type For Cable

Price: 35 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0008)

UHF Male Connector PL 259 Crimp Type For RG58, LMR300

Price: 40 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0015)

TNC Connector Waterproof Straight Bulkhead Female For Cable RG6_RG58_RG174

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~3 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-002-0044)

TNC Connector For Sale Straight 4Hole Flange Jack Solder Type For Panel Mount

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+165oC

Product Image (3AN-002-0060)

RG8 TNC Connector Clamp Type Coaxial Angled Plug For Cable

Price: 65 INR/Piece

Electrical Characteristics: Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+165oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image ( 3AN TELECOM)

UHF Male Connector For Cable Coaxial With Clamp Type

Price: 75 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-565)

UHF Male Coaxial Connector Straight Crimp Type For Cable

Price: 40 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0032)

UHF Female Connector Crimp Type Straight With Knurl For Cable

Price: 45 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof Material:

Product Image (3AN-009-0030)

UHF Female Connector For Cable Vertical And Solder Type With Straight

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0017)

UHF Female Bulkhead Connector R/A For Front Panel Mount

Price: 65 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0042)

UHF Female Coaxial Connector Straight Clamp Type For Cable

Price: 70 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0020)

UHF Connector Coaxial Straight Clamp Type Male For Cable

Price: 55 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-4555-25)

TNC Connector For RG8 Straight Male Crimp Type For Cable LMR400,RG213

Price: 5 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -40oC~+85oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0012)

UHF Connector Crimp Type PL 259 Male For Cable

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-002-0066)

TNC Female Bulkhead Connector Panel Mount Female Solder Type For Coaxial Cable

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~11 GHz for 50 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 3.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: 7/16-28 thread Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: -65oC~+145oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-009-0035)

UHF Connector Female Straight With 4 Hole Flange For Panel Mount

Price: 55 INR/Piece

Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C Weatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-009-0003)

UHF Connector Jack Right Angled Crimp Type For Cable

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics ImpedanceNon-constant Frequency Range: 0~300MHz Vlotage Rating: 500 volts peak Mechanical Characteristics Coupling: 5/8-24 threaded coupling Cable Affixment: Braid Solder, Set screw, clamp and crimp Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: Mica-filled phenolic insulators: -55C ~ +149C Copolymer of styrene and polystyrene: -55C ~ +85C TFE insulators: -65C ~ +165C eatherproof: Except as noted, all UHF series are non-weatherproof

Product Image (3AN-007-0162)

SMA Straight Cable Plug Crimp Type For Cable Gold Plating

Price: 30 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101 Material: Part Material Finish Body Brass Au:1u" Center Contact Pin Phosphor Au:3u" Insulator TEFLON White

Product Image (3AN-008-0072)

RF Connector SMB Type Male Crimp Type For Coaxial Cable

Price: 52 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact)

Product Image (3AN-1556-265)

SMB Bulkhead Connector Straight Female For Panel Mount

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact)

Product Image (3AN-008-0020)

Buy SMB Connector Straight Plug Crimp Type For RG316

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0050)

SMB Coax Right Angled Bulkhead Gold Plated Female For PCB

Price: 56 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0073)

SMB Coaxial Connector Male Crimp Type For Coaxial Cable

Price: 70 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0069)

SMB Male Straight Connector Crimp Type For Coaxial Gold Plating

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0068)

SMB Male Straight Crimp Type For Coaxial Cable

Price: 50 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-006-0090)

Clamp Type Coupling N Connector Female Straight Coaxial Connector

Price: 90 INR/Piece

Description:N Connector,Female/Jack,Straight/180,4 Hole Flange,Crimp Type,Coaxial Cable Features: N Connector,Female/Jack,Straight/180,4 Hole Flange,Crimp Type,Coaxial Cable; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0110)

Solder Type Coaxial Bulkhead Connector Straight Jack Connector

Price: 110 INR/Piece

Description:N Connector,Straight/180,Female/Jack,Front Bulkhead,Solder Type,Waterproof Accessories:nut+washer+o-ring Features: N Connector,Straight/180,Female/Jack,Front Bulkhead,Solder Type,Waterproof; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0130)

Flange Mount Type N Female Connector

Price: 55 INR/Piece

Description:N Connector,Female/Jack,Straight/180,4 Hole Flange,Through Hole,PCB Mount Features: N Connector,Female/Jack,Straight/180,4 Hole Flange,Through Hole,PCB Mount; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0038)

Angled Male Clamp Type N Connector

Price: 65 INR/Piece

Description: Cable Connector, plug/male, Angled/90,50,RG400 Features: Cable Connector, plug/male, Angled/90,50,RG400; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0125)

Jack Crimp Type N Bulkhead Connector

Price: 55 INR/Piece

Description:N Connector,RF Connector,Female/Jack,Straight/180,Front Bulkhead,Crimp Type Accessories:nut+washer+o-ring+pin Features: N Connector,RF Connector,Female/Jack,Straight/180,Front Bulkhead,Crimp Type; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0074)

Male Clamp Type N Coaxial Connector

Price: 45 INR/Piece

Description:N Connector,Male/Plug,Straight/180,Clamp Type Features: N Connector,Male/Plug,Straight/180,Clamp Type; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0098)

Cable Straight Jack Solder N Type Connector

Price: 55 INR/Piece

Description:N Connector,Female/Jack,Straight/180,Bulkhead,Solder Cup Accessories:nut+washer Features: N Connector,Female/Jack,Straight/180,Bulkhead,Solder Cup; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0112)

N Type Female Bulkhead Connector

Price: 105 INR/Piece

Description:N Connector,Straight/180,Female/Jack,Front Bulkhead, Crimp Type,Waterproof Accessories:nut+washer+o-ring Features: N Connector,Straight/180,Female/Jack,Front Bulkhead, Crimp Type,Waterproof; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0058)

N Type Jack Connector Straight Watertight 4 Hole Flange For Panel Mount

Price: 85 INR/Piece

Description: Panel Mount, jack/female, Straight/180,50,4Hole Flange Features: Panel Mount, jack/female, Straight/180,50,4Hole Flange; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-007-0007)

SMA Connector Straight Female For Edge Mount

Price: 55 INR/Piece

Description: Pcb Mount, Jack/female, Straight/180, 50,Edge Mount Features: Pcb Mount, Jack/female, Straight/180, 50,Edge Mount ; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0003)

RP-SMA Jack Connector Angled Gold Plated For PCB

Price: 35 INR/Piece

Description: Thru Hole,Pcb Mount,jack,RP, Angled/90, 50 Features: Thru Hole,Pcb Mount,jack,RP, Angled/90, 50; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-026-0010)

Coaxial RF Lightning Surge Protector SMA Male To Female Straight Connectors

Price: 310 INR/Piece

Description:Coaxial RF Lightning ArresterSMA,Male,SMA,FemaleStraight Product features: Coaxial RF Lightning ArresterSMA,Male,SMA,FemaleStraight Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionDC Pass; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0021)

FL Connect FL10 Male To Female Straight IP67 Coaxial RF Tube Surge Arrester Metric System

Price: 290 INR/Piece

Description:Coaxial RF Surge Protector,FL10 To FL10,Female To Female,Straight,IP67,Coaxial Connector Product features: Coaxial RF Surge Protector,FL10 To FL10,Female To Female,Straight,IP67,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionDC Pass; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0022)

FL Connector FL10 To FL10 Coaxial RF Lightning Surge Protector Male To Female IP67 Straight British System

Price: 290 INR/Piece

Description:Coaxial RF Surge Protector,FL10 To FL10,Female To Female,Straight,IP67,Coaxial Connector Product features: Coaxial RF Surge Protector,FL10 To FL10,Female To Female,Straight,IP67,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-006-0037)

N-Type Connector RG213 Male Crimp Type For Cable

Price: 60 INR/Piece

Description: Cable Connector, plug/male, Angled/90,Crimp Type ,50,RG400 Features: Cable Connector, plug/male, Angled/90,Crimp Type ,50,RG400; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image ( 3AN-006-0106)

RF Type N Female Straight Crimp Type For Coaxial Cable For RG6

Price: 35 INR/Piece

Description:N Connector,Straight/180,Female/Jack,Coaxial Connector,Crimp Type,RG6 Features: N Connector,Straight/180,Female/Jack,Coaxial Connector,Crimp Type,RG6; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0002)

RG58 Straight Male Crimp Type Connector

Price: 40 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50, Crimp Type, RG58, RG59, RG174, RG213 Accessories: pin+Ferrule Features: Cable Connector, plug/male, Straight/180, 50, Crimp Type, RG58, RG59, RG174, RG213; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc;

Product Image (3AN-006-0034)

Angled Male Crimp Type Cable Connector

Price: 65 INR/Piece

Description: Cable Connector, plug/male, Angled/90,CrimpType ,50,RG316 Features: Cable Connector, plug/male, Angled/90,CrimpType ,50,RG316; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0153)

Type N Connector Right Angle Female Blukhead Crimp Type For Cable

Price: 95 INR/Piece

Description:N Connector, Female/Jack,Right Angle/90,Cirmp Type,Coaxial Cable,Through Hole,Solder,Waterproof ,75Ohm,Nickel Plating Features: N Connector, Female/Jack,Right Angle/90,Cirmp Type,Coaxial Cable,Through Hole,Solder,Waterproof ,75Ohm,Nickel Plating Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-006-0118)

Types Of Coaxial Connectors N Male Crimp Type For Coaxial Cable

Price: 45 INR/Piece

Description:N Connector,Male/Plug,Straight/180,Crimp Type,Coaxial Connector Features: N Connector,Male/Plug,Straight/180,Crimp Type,Coaxial Connector; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-008-0008)

SMB Connector Jack Straight Crimp Type For Cable RG316

Price: 56 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0006)

SMB Jack Connector Angled Bulkhead For PCB Mount

Price: 60 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0046)

SMB Female Straight Bulkhead For PCB Mount

Price: 69 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0063)

SMB Female Straight Bulkhead Crimp Type For Cable

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0005)

SMB Connector Male Angled Through Hole For PCB Mount

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0053)

Smb Straight Plug Connector Crimp Type For RG316 Cable

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6GHz VSWR: Straight type:1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Insultation Resistance:5000 ohms min Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0082)

SMB Connector Female PCB Straight Through Hole 2 Holes Flange With Extended PTFE

Price: 65 INR/Piece

Description:SMB Connector,Straight,Female,Through Hole,2 Holes Flange,50 Ohm,Gold plating Features: SMB Connector,Straight,Female,Through Hole,2 Holes Flange,50 Ohm,Gold plating; Snap-on coupling design for fast installation; With boardband performance and low reflection; To reduce your Cost by using die casting process in non-critical areas. From the OEM Original Factory, same quality with much better price. Main Application of SMB Connectors: Aerospace and Defense: Test Stands Medical: Telemetry Commercial Vehicle: GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications: Routers, WIFI, Radio Boards Industrial: M2M Communications, Process Controls, Video Systems, Instrumentation

Product Image (3AN-008-0045)

SMB Straight Gold Plated Female End Launch For Mount

Price: 40 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0045)

SMB Female Connectors Straight 2 Hole Flange Solder Type For Cable

Price: 55 INR/Piece

Description:SMB Connector,Straight/180,Female/Jack, Gold Plating,Solder Type,Coaxial Cable Features: SMB Connector,Straight/180,Female/Jack, Gold Plating,Solder Type,Coaxial Cable; Snap-on coupling design for fast installation; With boardband performance and low reflection; To reduce your Cost by using die casting process in non-critical areas. From the OEM Original Factory, same quality with much better price.

Product Image (3AN-008-0016)

SMB Female Right Angle Connector Through Hole For PCB Mount

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0051)

SMB Female Right Angle Connector Gold Plating Through Hole For PCB Mount

Price: 60 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-006-0046)

N Connector Female Bulkhead

Price: 85 INR/Piece

Description: Panel Mount, jack/female, Straight/180,50,RG142,RG400,RG223, Bulkhead, Cable Connector Accessories: nut+washer+o-ring Features: Panel Mount, jack/female, Straight/180,50,RG142,RG400,RG223, Bulkhead, Cable Connector; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-008-0057)

SMB Straight Connector Plug Crimp Window Solder

Price: 56 INR/Piece

Main Application of SMB Connectors: Aerospace and Defense: Test Stands Medical: Telemetry Commercial Vehicle: GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications: Routers, WIFI, Radio Boards Industrial: M2M Communications, Process Controls, Video Systems, Instrumentation Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0090)

SMA Angled 4Hole Square Flange Male For Panle Mount With PTFE

Price: 75 INR/Piece

Description:Panel Mount, plug/male, Angled/90, 50, 4Hole Flange Features: Panel Mount, plug/male, Angled/90, 50, 4Hole Flange; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-006-0105)

Male N Type Crimp Type Coaxial Connector

Price: 35 INR/Piece

Description:N Connector,Male/Plug,Straight/180,Crimp Type,Coaxial Connector Accessories:Ferrule Features: N Connector,Male/Plug,Straight/180,Crimp Type,Coaxial Connector; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-008-0015)

SMB Straight Connector 75 Ohm Female For Edge Mount

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0052)

Smb Straight Connector Gold Plated Female Connector For PCB Mount

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-006-0003)

RG58 Male Straight Crimp Type N Connector

Price: 45 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50, Crimp Type, RG58 Accessories: pin+Ferrule Features: Cable Connector, plug/male, Straight/180, 50, Crimp Type, RG58; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0031)

LMR-400 Straight Jack N Connectors

Price: 55 INR/Piece

Description: Cable Connector, jack/female, Straight/180,Crimp Type ,50,RG213 Features: Cable Connector, jack/female, Straight/180,Crimp Type ,50,RG213; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0066)

N Male RF Coax Straight Dust Cap With Chain

Price: 55 INR/Piece

Description: plug/male, Straight/180,50, Dust Cap, Chain Features: plug/male, Straight/180,50, Dust Cap, Chain; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0095)

N Type Bulkhead Connector

Price: 85 INR/Piece

Description:N Connector,Adapter,Straight/180,Female to Female,Waterproof,Bulkhead Features: N Connector,Adapter,Straight/180,Female to Female,Waterproof,Bulkhead; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0080)

N Type Connector

Price: 120 INR/Piece

Description:N Connector,Female/Jack,Straight/180,Clamp Type,4 Hole Flange Features: N Connector,Female/Jack,Straight/180,Clamp Type,4 Hole Flange; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0072)

Female Straight Front Bulkhead Crimp Type N Type Connector

Price: 75 INR/Piece

Description:N Connector,Female/Jack,Straight/180,Clamp Type,Waterproof Accessories: Features: N Connector,Female/Jack,Straight/180,Clamp Type,Waterproof; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0012)

Bulkhead Female N Type Connector

Price: 45 INR/Piece

Part No: 3AN-006-0012 Description: Panel Mount, Jack/female, Straight/180, 50, bulkhead Accessories: nut+washer Features: Panel Mount, Jack/female, Straight/180, 50, bulkhead; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0022)

N Type Connector For RG214 Male Crimp Type For Cable

Price: 75 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50, Crimp Type,RG214 Features: Cable Connector, plug/male, Straight/180, 50, Crimp Type,RG214; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0051)

Panel Mount Straight Male N Type Connector

Price: 95 INR/Piece

Description: Panel Mount, plug/male, Straight/180,50, 4Hole Flange Features: Panel Mount, plug/male, Straight/180,50, 4Hole Flange; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0024)

N Type Connector RG214 Plug Clamp Type For Cable RG213,LMR400

Price: 55 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50,RG213,LMR400,Clamp Type Features: Cable Connector, plug/male, Straight/180, 50,RG213,LMR400,Clamp Type; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-007-0019)

4Hole Square Flange Straight SMA RF Plug Connector For Panel Mount

Price: 40 INR/Piece

Description: Panel Mount, Plug/Male, Straight/180, 50,Flange Features: Panel Mount, Plug/Male, Straight/180, 50,Flange; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0198)

Crimp Type Connector SMA Female For RG316 Coaxial Cable

Price: 25 INR/Piece

Description:SMA Connector,Female/Jack,Straight/180,Crimp Type,Cable Connector,Gold Plating Features: SMA Connector,Female/Jack,Straight/180,Crimp Type,Cable Connector,Gold Plating; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Appliance: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0301)

SMA 2 Hole Flange Connector Female Straight Cirmp Type Coaxial Cable

Price: 40 INR/Piece

Description:SMA Connector,Vertical Type/180,Female,2 Hole Flange,Cirmp Type,Coaxial Cable,Solder,50Ohm ,Gold Plating Features: SMA Connector,Vertical Type/180,Female,2 Hole Flange,Cirmp Type,Coaxial Cable,Solder,50Ohm ,Gold Plating Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Appliance: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0055)

SMA 2 Hole Flange Straight Plug With Extended PTFE

Price: 55 INR/Piece

Description: Panel Mount, Plug/male, straight/180, 50, 2Hole Flange,Extended Features: Panel Mount, Plug/male, straight/180, 50, 2Hole Flange,Extended; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0053)

SMA 2-Hole Flange Straight Plug For Panel Mount

Price: 45 INR/Piece

Description: Panel Mount, plug/male, straight/180, 50, 2Hole Flange Features: Panel Mount, plug/male, straight/180, 50, 2Hole Flange; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0282)

Connector Long Thread Female Planel Mount Through Hole

Price: 65 INR/Piece

Description:SMA Connector,Female,Angled/90,Through Hole,PCB Mount,50Ohm,Gold Plating Features: SMA Connector,Female,Angled/90,Through Hole,PCB Mount,50Ohm,Gold Plating Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design;

Product Image (3AN-007-0018)

SMA Coaxial Connector Female Straight Square Flange For Panel Mount

Price: 60 INR/Piece

Description: Panel Mount, Jack/Female, Straight/180, 50,Flange Features: Panel Mount, Jack/Female, Straight/180, 50,Flange; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0013)

SMA Connector Female Angled 4Hole Square Flange For Panel Mount

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0011)

SMA Connector Gold Plated Straight Male For PCB

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0094)

SMA Connector Panel Mount Right Angle 2 Hole Flange Jack

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~18 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0191)

SMA Connector Panel SMT For PCB Mount Female Gold Plating

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0024)

SMA Connector Plug Straight Crimp Type For Cable RG58,59

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0286)

Through Hole SMA Connector Jack Right Angled Gold Plating 50 Ohm PCB Mount

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0287)

Through Hole SMA DIP RP Female Panel Mount PCB Mount

Price: 56 INR/Piece

Description:SMA Connector,Right Angled,Female,50Ohm,Through Hole,Gold Plating Features: SMA Connector,Right Angled,Female,50Ohm,Through Hole,Gold Plating Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Appliance: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0156)

SMA Straight Jack RF Connector Bulkhead Crimp Window Solder

Price: 30 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0084)

SMA Straight Bulkhead Plug Gold Plated Connector

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~18 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact)

Product Image (3AN-007-0126)

SMA Male Dust Cap With Steel Chain Gold Plated

Price: 56 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~12.4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0132)

SMA Female Right Angle PCB Mount Through Hole Type

Price: 75 INR/Piece

Description: PCB Mount, Jack/female, Angled/90, 50, Through Hole Type Features: PCB Mount, Jack/female, Angled/90, 50, Through Hole Type; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Appliance: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0161)

SMA Female Crimp Connector Bulkhead Gold Plating

Price: 30 INR/Piece

Description:SMA Connector,Female/Jack,Straight/180,Bulkhead,Crimp Type,Coxial Cable Features: SMA Connector,Female/Jack,Straight/180,Bulkhead,Crimp Type,Coxial Cable; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price.

Product Image (3AN008-0056)

SMB Connector Female Crimp Type For Cable Gold Plating

Price: 56 INR/Piece

Description: SMB Connector,Right Angled/90,Female/Jack,Crimp Type,Coaxial C able Accessories: Ferrule+insulator+cover Features: SMB Connector,Right Angled/90,Female/Jack,Crimp Type,Coaxial C able ; Snap-on coupling design for fast installation; With boardband performance and low reflection; To reduce your Cost by using die casting process in non-critical areas. From the OEM Original Factory, same quality with much better price. Main Application of SMB Connectors: Aerospace and Defense: Test Stands Medical: Telemetry Commercial Vehicle: GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications: Routers, WIFI, Radio Boards Industrial: M2M Communications, Process Controls, Video Systems, Instrumentation

Product Image (3AN-008-0076)

SMB Connector Male Right Angled Through Hole For PCB Mount

Price: 56 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0081)

Female SMB Angled Throegh Hole Connector For PCB Mount

Price: 65 INR/Piece

Description:SMB Connector,Female,Angled,PCB Mount,Through Hole,Copper,Gold Plating Features: SMB Connector,Female,Angled,PCB Mount,Through Hole,Copper,Gold Plating; Snap-on coupling design for fast installation; With boardband performance and low reflection; To reduce your Cost by using die casting process in non-critical areas. From the OEM Original Factory, same quality with much better price. Main Application of SMB Connectors: Aerospace and Defense: Test Stands Medical: Telemetry Commercial Vehicle: GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications: Routers, WIFI, Radio Boards Industrial: M2M Communications, Process Controls, Video Systems, Instrumentation

Product Image (3AN-008-0071)

Female SMB Connector For Coaxial Cable Gold Plating

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0017)

SMB Connectors Plug Straight Coax For Cable

Price: 70 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0001)

SMB Connector PCB Mount Female Straight Through Hole

Price: 55 INR/Piece

Description: Pcb Mount, Jack/female, Straight/180, 75, Through Hole Features: Pcb Mount, Jack/female, Straight/180, 75, Through Hole; Snap-on coupling design for fast installation; With boardband performance and low reflection; To reduce your Cost by using die casting process in non-critical areas. From the OEM Original Factory, same quality with much better price. Main Application of SMB Connectors: Aerospace and Defense: Test Stands Medical: Telemetry Commercial Vehicle: GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications: Routers, WIFI, Radio Boards Industrial: M2M Communications, Process Controls, Video Systems, Instrumentation

Product Image (3AN-008-0007)

SMB Connector Plug Solder Type For Semi Rigid Cable

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.)

Product Image (3AN-008-0061)

SMB Right Angle Connector Male Crimp Type For Cable

Price: 56 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 04 GHz VSWR: Straight type ‰ 1.3max / R/A type ‰ 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance ‰ 6.0 mÎ (Milliohms max.) Outer Contact Resistance 1.5 mÎ (Milliohms max.) Insultation Resistance ‰ 1000 mÎ(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: ‰500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-026-0030)

TNC Male To Female Lightning Arrester Surge Protector IP67 Straight DC-3GHz

Price: 320 INR/Piece

Description:Coaxial RF Surge Protector,TNC To TNC,Male To Female,Straight,IP67,DC-3GHz,Coaxial Connector roduct features: Coaxial RF Surge Protector,TNC To TNC,Male To Female,Straight,IP67,DC-3GHz,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0031)

TNC Connector Male To Female Coaxial RF Surge Protector Straight IP67 DC-2.5GHz

Price: 350 INR/Piece

Description:Coaxial RF Surge Protector,TNC To TNC,Male To Female,Straight,IP67,DC-2.5GHz,Coaxial Connector Product features: Coaxial RF Surge Protector,TNC To TNC,Male To Female,Straight,IP67,DC-2.5GHz,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0015)

Surge Arrester N Male To Female Straight IP67 Nickel Plating N-JKY RF Coaxial

Price: 290 INR/Piece

Description:RF Coaxial Surge Arrester,N to N,Male To Female,Straight,IP67,Nickel Plating,Coaxial Connector Product features: RF Coaxial Surge Arrester,N to N,Male To Female,Straight,IP67,Nickel Plating,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-008-0061)

SMB Right Angle Connector Male Crimp Type For Cable

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 04 GHz VSWR: Straight type ‰ 1.3max / R/A type ‰ 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance ‰ 6.0 mÎ (Milliohms max.) Outer Contact Resistance 1.5 mÎ (Milliohms max.) Insultation Resistance ‰ 1000 mÎ(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: ‰500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-006-0004)

N Type Connector

Price: 55 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50Î, Clamp Type, LMR200, LMR300 Features: Cable Connector, plug/male, Straight/180, 50Î, Clamp Type, LMR200, LMR300; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (: 3AN-026-0029)

SMA Male To Female DC-6GHz Coaxial RF Surge Protector 180 IP67

Price: 250 INR/Piece

Description:Coaxial RF Surge Protector,SMA To SMA,Male To Female,Straight,IP67,DC-6GHz,Coaxial Connector Product features: Coaxial RF Surge Protector,SMA To SMA,Male To Female,Straight,IP67,DC-6GHz,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0003)

RF Load Connector N Male Straight Square Black Lightning Arrester

Price: 380 INR/Piece

Description:N Load ConnectorMale,StraightStandard,Thread Coupling Product features: N Load ConnectorMale,StraightStandard,Thread Coupling Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0006)

SMA Male Load Lightning Arrester Black Straight Circular Connectors

Price: 250 INR/Piece

Description:SMA Load ConnectorMale,StraightStandard,Thread Coupling Product features: SMA Load ConnectorMale,StraightStandard,Thread Coupling Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-007-0302)

SMA Connector Female Cirmp Type Cable Blukhead Panel Mount

Price: 35 INR/Piece

Description:SMA Connector,Right Angle/90,Female,Cirmp Type,Coaxial Cable,Blukhead,Panel Mount,Solder,50Ohm ,Gold Plating Features: SMA Connector,Right Angle/90,Female,Cirmp Type,Coaxial Cable,Blukhead,Panel Mount,Solder,50Ohm ,Gold Plating Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Appliance: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0006)

SMA Connector Female Cirmp Type Cable Blukhead Panel Mount

Price: 40 INR/Piece

Description: Pcb Mount, Jack/female, Straight/180, 50Î,Edge Mount Features: Pcb Mount, Jack/female, Straight/180, 50Î,Edge Mount; Excellent electrical performance up to 18GHz with low reflection; Thread type coupling mechanism ensure small loss and high security in compact design; From the OEM Original Factory, same quality with much better price. Main Application of SMA Connectors: Aerospace and Defense: Hand-held field Device and Instrumentation Medical: Instrumentation Commercial Vehicle: Bluetooth and GPS Telecommunications: Wireless Base Stations, Cellular Mobile System Data/Communications:Wifi, WiMAX Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking System

Product Image (3AN-007-0034)

SMA Connector Crimping Type Angled Female For RG316

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 06 GHz VSWR: Straight type ‰ 1.3max / R/A type ‰ 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance ‰ 6.0 mÎ (Milliohms max.) Outer Contact Resistance ‰ 2.0 mÎ (Milliohms max.) Insultation Resistance ‰ 5 x 10³ mÎ (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) ‰ 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-026-0008)

N Type Attenuator Male Butt-Joint Female Straight N RF Coaxial Attenuator Connectors DC-3GHz 30W 10dB Lightning Arrester

Price: 429 INR/Piece

Description:Rf coaxial attenuatorN,Male,N,FemaleStraightDC-3GHz,30W,10dB Product features: Rf coaxial attenuatorN,Male,N,FemaleStraightDC-3GHz,30W,10dB Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0014)

N Connectors Dummy Load Female Straight 10W 4GN30 Attenuator

Price: 290 INR/Piece

Description: N Load Connector,Male,Female,Straight,10W,4GN30,Attenuator Product features: N Load Connector,Male,Female,Straight,10W,4GN30,Attenuator Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-007-0005)

SMA Connector Coaxial Angled Female For PCB Mount

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-026-0002)

Coaxial RF Lightning Arrester DIN Male Butt-Joint Female T Type IP67 Straight Nickel Plating

Price: 290 INR/Piece

Description:Coaxial RF Lightning ArresterDIN,FemaleDIN,MaleStraightNickel Plating Product features: Coaxial RF Lightning ArresterDIN,FemaleDIN,MaleStraightNickel Plating Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0025)

N Male To N Female Bulkhead Coaxial RF Lightning Arrester N-JKY DC-3GHz IP67

Price: 320 INR/Piece

Description:Coaxial RF Surge Protector,N Type To N Type,Male To Female,Straight,IP67,DC-3GHz,Coaxial Connector Product features: Coaxial RF Surge Protector,N Type To N Type,Male To Female,Straight,IP67,DC-3GHz,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protection;DC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0026)

N Male To N Female Adapter IP67 DC-6GHz Straight Lightning Arrester Surge Protector

Price: 320 INR/Piece

Description:Coaxial RF Surge Protector,N Type To N Type,Male To Female,Straight,IP67,DC-6GHz,Coaxial Connecto Product features: Coaxial RF Surge Protector,N Type To N Type,Male To Female,Straight,IP67,DC-6GHz,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0007 )

N Male Load Connector Black Lightning Arrester Straight Coaxial Pseudo Load Connector

Price: 280 INR/Piece

Description:N Load ConnectorMale,StraightStandard,thread coupling Product features: N Load ConnectorMale,StraightStandard,thread coupling Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-007-0036)

SMA Connector Coaxial Cable Female Bulkhead

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~18 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-026-0020)

N Female Connector N Female To N Male Lightning Arrester Surge Protector IP67 Nickel Plating

Price: 310 INR/Piece

Description:Coaxial RF Surge Protector,N Type To N Type,Male To Female,Straight,Nickel Plating,IP67,Coaxial Connector Product features: Coaxial RF Surge Protector,N Type To N Type,Male To Female,Straight,Nickel Plating,IP67,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-026-0016)

Lightning Arrester RF Coaxial Nickel Plating Straight N-JKY N Male To Female IP67

Price: 290 INR/Piece

Description:RF Coaxial Surge Arrester,N to N,Male To Female,Straight,IP67,Nickel Plating,Coaxial Connector Product features: RF Coaxial Surge Arrester,N to N,Male To Female,Straight,IP67,Nickel Plating,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-124-55)

SMA Connector Female Panel Mount Coaxial 2Hole Flange

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0017)

SMA Connector 2Hole Flange Straight Female For Panel Mount

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101 Material: Part Material Finish Body Brass Au:1u" insulator TEFLON White Center Contact Pin Phosphor Au:3u"

Product Image (3AN-007-0009)

SMA Connector Right Angled Male For PCB Mount

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0254)

SMA Connector Types Female Straight For RG8 Cable

Price: 35 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-026-0009)

Coaxial RF Connector N Male Butt-Joint Female Straight T Type Coaxial RF Lightning Arrester

Price: 280 INR/Piece

Description:Coaxial RF Lightning ArresterN,Male,N,FemaleStraight Product features: Coaxial RF Lightning ArresterN,Male,N,FemaleStraight Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability Bi-directional protectionãDC Pass; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-007-0129)

SMA Connector 4 Hole Flange Famale Straight For Panel Mount

Price: 85 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~18 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -65C ~ +125C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0012)

SMA Connector Female Straight Edge Mount For PCB Mount

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-026-0024)

L27 Connector DC-2GHz Straight IP67 Coaxial RF Surge Protector L27-JK Male To Female

Price: 340 INR/Piece

Description:Coaxial RF Surge Protector,L27 To L27,Male To Female,Straight,IP67,DC-2GHz,Coaxial Connector Product features: Coaxial RF Surge Protector,L27 To L27,Male To Female,Straight,IP67,DC-2GHz,Coaxial Connector Special shielding design, excellent surge performance, can withstand multiple lightning strikes; Excellent passive intermodulation performance, excellent rf performance in the whole working band and superior power processing capability¼› Bi-directional protectionDC Pass; From the OEM Original Factory, same quality with much better price. Appliance: 3G/4G/LTE Cellular Modems Routers Boosters/Amplifiers 2.4&5GHz WiFi Access Points other Sensitive Communications Devices

Product Image (3AN-007-0023)

SMA Connector For RG316 Crimp Type Straight Plug For Cable RG174

Price: 35 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0047)

SMA Connector RG174 Coaxial Cable Straight Bulkhead Female For RG316

Price: 40 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~18 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -45C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0040)

SMA Connector Soldering Type Bulkhead Female Waterproof For UT085

Price: 35 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~18 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -45C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN007-0281)

SMA Connector Right Angled Through Hole Gold Plating Panel Mount

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0021)

SMA Connector Bulkhead Female Straight Solder Type For Cable RG316

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact)

Product Image (3AN-008-0025)

Right Angle SMB Connector Male Solder Type For Cable

Price: 70 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-006-0076)

Plug Solder Type N Connector

Price: 75 INR/Piece

Description:N Connector,Male/Plug,Right Angled/90,Solder Type,Coaxial Connector Features: N Connector,Male/Plug,Right Angled/90,Solder Type,Coaxial Connector; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0014)

Bulkhead Straight Jack Crimp Type N Connector

Price: 65 INR/Piece

Description: Cable Connector, Jack/female, Straight/180, 50, bulkhead, Crimp Type, RG316, RG174 Accessories: nut+washer Features: Cable Connector, Jack/female, Straight/180, 50, bulkhead, Crimp Type, RG316, RG174; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-006-0005)

RG 213 Angled Male Crimp Type N Connector

Price: 75 INR/Piece

Description: Cable Connector, plug/male, Angled/90, 50, Crimp Type, RG58, RG59, RG6, RG174, RG213 Accessories: Ferrule+insulator+cover Features: Cable Connector, plug/male, Angled/90, 50, Crimp Type, RG58, RG59, RG6, RG174, RG213; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of N Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-008-0078)

Right Angle SMB Male Crimp Type For Rg174 Cable

Price: 70 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance:3mW Outer Contact Resistance:25mW Insultation Resistance:5GW Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0026)

SMA Connector RG316 Right Angled Male Crimp Type For Cable

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -55C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-007-0136)

SMA Female Panel Mount Connector Straight Through Hole

Price: 45 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~6 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage:1000 V rms min for RG142, RG405 750 V rms min. for RG316, RG402 500v rms min. for RG178 Working Voltage: 500 V rms max. for RG142, RG405 375 V rms max. for RG316, RG402 170 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 x 10 m (Megohms min.) Mechanical Characteristics Coupling: 1/4-36 thread Contact Retention: 15 in-lbs min. Coupling nut torque: 30 in-lbs. min. Durability(mating) 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Temprature Range: -65C ~ +165C Vibration: MIL-STD-202 Meth.204 Corrosion resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0019)

SMB Connectors Coax Straight Male Crimp Type For Cable RG178

Price: 75 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-008-0028)

SMB Connector Right Angle Plug For Cable RG178

Price: 70 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 1000 V rms min for RG316, RG402 750 V rms min. for RG178 Working Voltage: 335 V rms max. for RG316, RG402 250 V rms max. for RG178 Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 1.5 m (Milliohms max.) Insultation Resistance 1000 m(Megohms min.) Mechanical Characteristics Coupling: Snap-on Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +155C Vibration: MIL-STD-202 Meth.204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-006-0019)

Cable Straight Male N Type Connector

Price: 35 INR/Piece

Description:Cable Connector, plug/male, Straight/180, 50, Solder Type, UT250 Features: Cable Connector, plug/male, Straight/180, 50, Solder Type, UT250; Great performance with DC to 11GHz Frequency and 50 ohm impedance; Threaded coupling mechanism ensure durability and stability for vibration application; Medium size used in military, industry or consumption electronic area, etc; From the OEM Original Factory, same quality with much better price. Main Application of F Connectors: Aerospace and Defense: Radar Equipment Medical: Ablation equipment Commercial Vehicle: Bluetooth and GPS Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware Data/Communications: Broadcast Electronics, Wifi Industrial: Machine to Machine Communications

Product Image (3AN-014-0013)

Fakra Z Male Water Blue Crimp Solder Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,50 Ohm,Crimp,Solder,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Crimp,Solder,for Cable,RG316,RG174,Brass,Nickel plating; FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-023-0002)

FME Connector Jack Straight Cable Mount Crimp Termination

Price: 35 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance:50 Ohm Frequency Range: DC- 200MHz VSWRï1.20@DC-3GHz Dielectric Withstanding Voltage:ï1000V RMS,50Hz Dielectric Resistance: ï5000 MOhm Working Voltage : ï1000V Contact Resistance: Center Contact ï2.5m Ohm Outer Contact ï3.0m Ohm Mechanical Characteristics Mating M8XP 0.75 Thread Durability (Mating times): ï500 These characteristics are typical and may not apply to all connectors. Environmental Characteristics Temperature Range-65C to +165C Material: Part Material Finish Body BRASS Au:1u" insulator TEFLON WHITE Center Contact Pin BRASS Au:3u"

Product Image (3AN-014-0024)

Female Fakra H Crimp Solder

Price: 155 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0022)

FME Connector Jack Straight Cable Mount Crimp Termination

Price: 35 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0024)

Female Fakra H Crimp Solder

Price: 165 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-004-0046)

Gold Plated Crimp Straight Window Solder MCX Plug Connector

Price: 85 INR/Piece

Description:MCX Connector,Male/Plug,Straight/180,Crimp Window Solder,Gold Plated AccessoriesFerrule Features: MCX Connector,Male/Plug,Straight/180,Crimp Window Solder,Gold Plated; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-003-0095)

F Type Connector Bulkhead Straight Female Crimp Window Solde

Price: 145 INR/Piece

Description: F Type Connector,Female,Straight/180,Crimp Type,Coaxial Cable Product features: F Type Connector,Female,Straight/180,Crimp Type,Coaxial Cable Compact Design for less installation space required; Easy quick connect and disconnect coupling; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-003-0095)

F Type Connector Bulkhead Straight Female Crimp Window Solde

Price: 70 INR/Piece

Description: F Type Connector,Female,Straight/180,Crimp Type,Coaxial Cable Product features: F Type Connector,Female,Straight/180,Crimp Type,Coaxial Cable Compact Design for less installation space required; Easy quick connect and disconnect coupling; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0033)

RG11 F Connector Male Straight Brass

Price: 40 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 75, RG11 Features: Cable Connector, plug/male, Straight/180, 75, RG6; Great security and tamper protection performance with screw on structure; Simple structure and component to produce F connectors in very competitive price; Less than 30 seconds required for wiring make it really easy to install; Can be visually inspect even after connection; From the OEM Original Factory, same quality with much better price. Main Application of F Connectors: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks

Product Image (3AN-003-0058)

RG11 F Type Connector Coaxial Straight Male

Price: 56 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 75, Compression Type,RG11 Product features: Cable Connector, plug/male, Straight/180, 75, Compression Type,RG11; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0094)

Right Angled F Type Connector Male Crimp Type

Price: 35 INR/Piece

Description: F Type Connector,Male/Plug,Straight/180,Right Angled,Crimp Type,Coaxial Cable Product features: F Type Connector,Male/Plug,Straight/180,Right Angled,Crimp Type,Coaxial Cable Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-014-0041)

Fakra C Female Blue Crimp Connector

Price: 155 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,Crimp,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,Crimp,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0042)

Fakra Connector Green E Male Green Crimp Solder Connector

Price: 125 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,Solder,Crimp,for Cable,RG316,RG174,,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,Solder,Crimp,for Cable,RG316,RG174,,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0038)

Fakra Connector K Female Curry

Price: 135 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-004-0005)

RG174 Plug Crimp Type MCX Connector

Price: 85 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 75, Crimp Type, RG174 Accessories: pin+ferrule Features: Cable Connector, plug/male, Straight/180, 75, Crimp Type, RG174; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0049)

Right Angle Male Gold Plated Crimp Type MCX Connector

Price: 65 INR/Piece

Description:MCX Connector,Male/Plug,Right Angled/90,Solder Type,Gold Plated AccessoriesFerrule+insulator+Washer Features: MCX Connector,Male/Plug,Right Angled/90,Solder Type,Gold Plated; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0008)

Right Angled Crimp Type MCX Plug Connector

Price: 85 INR/Piece

Description: Cable Connector, plug/male, Angled/90, 50, Crimp Type, RG316, Crimp Type Accessories: Ferrule+ insulator+cover Features: Cable Connector, plug/male, Angled/90, 50, Crimp Type, RG316, Crimp Type; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0030)

MCX RF Coax Connector Straight 2 Hole Flange Jack For Panel Mount

Price: 95 INR/Piece

Description: Straight/180,jack/famale,Flange,Panel Mount,50 Features: Straight/180,jack/famale,Flange,Panel Mount,50; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0044)

MCX RF Connector Male Straight Gold Plated Crimp

Price: 55 INR/Piece

Description:MCX Connector,Male/Plug,Straight/180,Crimp Type,Gold Plated Connector,Female/Jack,Straight/180,SMT,PCB Mount,Gold Plated Features: MCX Connector,Male/Plug,Straight/180,Crimp Type,Gold Plated; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0038)

MCX Straight Connector Coax Female Through Hole

Price: 75 INR/Piece

Description: Pcb Mount, Straight/180,50,jack/female, Through Hole Features: Pcb Mount, Straight/180,50,jack/female, Through Hole; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0045)

Right Angled Male Solder Type MCX Type Connector

Price: 75 INR/Piece

Description:MCX Connector,Male/Plug,Right Angled/90,Solder Type,Gold Plated AccessoriesWasher+Insulator Features: MCX Connector,Male/Plug,Right Angled/90,Solder Type,Gold Plated; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-005-0002)

MMCX Connector Crimp Type Right Angled Plug

Price: 30 INR/Piece

Description: Cable Connector, plug/male, Angled/90, 50, Crimp Type Accessories: ferrule+insulator+cover Features: Cable Connector, plug/male, Angled/90, 50, Crimp Type; Micro-miniature version of MCX with all features of MCX series conenctor.; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MMCX Connectors: Consumer Electronic: Smart phones GPS and wireless antennas, Aerospace and Defense: GPS Medical: Medical Devices Telecommunications: GPS tracking, positioning and navigation devices, Wireless Base Station, Wireless-LAN, Wireless antennas Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Computer connections-LAN/WAN

Product Image (3AN-005-0036)

Female Straight Gold Plated Crimp Type MMCX Connector

Price: 55 INR/Piece

Description:MMCX Connector,Female/Jack,Straight/180,Crimp Type,Gold Plated Accessories :ferrule+pin Features: MMCX Connector,Female/Jack,Straight/180,Crimp Type,Gold Plated; Micro-miniature version of MCX with all features of MCX series conenctor.; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MMCX Connectors: Consumer Electronic: Smart phones GPS and wireless antennas, Aerospace and Defense: GPS Medical: Medical Devices Telecommunications: GPS tracking, positioning and navigation devices, Wireless Base Station, Wireless-LAN, Wireless antennas Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Computer connections-LAN/WAN

Product Image (3AN-005-0006)

MMCX Crimp Connector Plug

Price: 65 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50, Crimp Type Accessories: pin+ferrule Features: Cable Connector, plug/male, Straight/180, 50, Crimp Type; Micro-miniature version of MCX with all features of MCX series conenctor.; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MMCX Connectors: Consumer Electronic: Smart phones GPS and wireless antennas, Aerospace and Defense: GPS Medical: Medical Devices Telecommunications: GPS tracking, positioning and navigation devices, Wireless Base Station, Wireless-LAN, Wireless antennas Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Computer connections-LAN/WAN

Product Image (3AN-005-0008)

Male Solder Type MMCX RF Connector

Price: 40 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 50, Solder Type, UT086 Features: Cable Connector, plug/male, Straight/180, 50, Solder Type, UT086; Micro-miniature version of MCX with all features of MCX series conenctor.; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MMCX Connectors: Consumer Electronic: Smart phones GPS and wireless antennas, Aerospace and Defense: GPS Medical: Medical Devices Telecommunications: GPS tracking, positioning and navigation devices, Wireless Base Station, Wireless-LAN, Wireless antennas Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Computer connections-LAN/WAN

Product Image (3AN-005-0029)

Right Angled Male Crimp Type MMCX RF Connector

Price: 55 INR/Piece

Description:MMCX Connector,Male/Plug,Right Angled/90,Crimp Type,Gold Plated Features: MMCX Connector,Male/Plug,Right Angled/90,Crimp Type,Gold Plated; Micro-miniature version of MCX with all features of MCX series conenctor.; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MMCX Connectors: Consumer Electronic: Smart phones GPS and wireless antennas, Aerospace and Defense: GPS Medical: Medical Devices Telecommunications: GPS tracking, positioning and navigation devices, Wireless Base Station, Wireless-LAN, Wireless antennas Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Computer connections-LAN/WAN

Product Image (3AN-005-0015)

Plug Solder Type MMCX Right Angle Connector

Price: 30 INR/Piece

Description: Cable Connector, plug/male, Angled/90, 50, Solder Type Accessories: insulator+cover Features: Cable Connector, jack/female, Straight/180, 50, Crimp Type,RG316; Micro-miniature version of MCX with all features of MCX series conenctor.; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MMCX Connectors: Consumer Electronic: Smart phones GPS and wireless antennas, Aerospace and Defense: GPS Medical: Medical Devices Telecommunications: GPS tracking, positioning and navigation devices, Wireless Base Station, Wireless-LAN, Wireless antennas Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Computer connections-LAN/WAN

Product Image (3AN-023-0003)

FME Connector Plug Straight Cable Mount Crimp Termination

Price: 55 INR/Piece

Description:Male, Straight,Crimp,Cable Mount, Nickel,50,2GHz,RG141 A/U Features: Male, Straight,Crimp,Cable Mount, Nickel,50,2GHz,RG141 A/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance From the OEM Original Factory, same quality with much better price.

Product Image (3AN-023-0001)

FME Connector Straight Cable Mount

Price: 45 INR/Piece

Description:Female, Straight,Crimp,Cable Mount, Nickel,50,2GHz,RG141 A/U Features: Female, Straight,Crimp,Cable Mount, Nickel,50,2GHz,RG141 A/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Main Application of FME Connectors: Mil-Aero Telecommunication Cellular base stations Wireless defense applications Radar systems

Product Image (3AN-023-0009)

FME Crimp Straight Cable Mount Connector Jack Termination

Price: 45 INR/Piece

Description:Female, Straight,Crimp,Cable Mount, Nickel,50,2GHz, RG174/U Features: Female, Straight,Crimp,Cable Mount, Nickel,50,2GHz, RG174/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance From the OEM Original Factory, same quality with much better price. Main Application of FME Connectors: Mil-Aero Telecommunication Cellular base stations Wireless defense applications Radar systems

Product Image (3AN-023-0009)

FME Crimp Straight Cable Mount Connector

Price: 55 INR/Piece

Description:Female, Straight,Crimp,Cable Mount, Nickel,50,2GHz, RG174/U Features: Female, Straight,Crimp,Cable Mount, Nickel,50,2GHz, RG174/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance From the OEM Original Factory, same quality with much better price. Main Application of FME Connectors: Mil-Aero Telecommunication Cellular base stations Wireless defense applications Radar systems

Product Image (3AN-023-0011)

FME Straight Jack Cable Mount Connector

Price: 55 INR/Piece

Description:Female, Straight,Crimp,Cable Mount, Nickel,50,2MHz, RG58/U Features: Female, Straight,Crimp,Cable Mount, Nickel,50,2MHz, RG58/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance From the OEM Original Factory, same quality with much better price. Main Application of FME Connectors: Mil-Aero Telecommunication Cellular base stations Wireless defense applications Radar systems

Product Image (3AN-023-0006)

FME Straight Cable Mount Connector

Price: 56 INR/Piece

Description:Female, Straight,Crimp,Cable Mount, Nickel,50,1.8GHz, RG174/U Features: Female, Straight,Crimp,Cable Mount, Nickel,50,1.8GHz, RG174/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance From the OEM Original Factory, same quality with much better price. Main Application of FME Connectors: Mil-Aero Telecommunication Cellular base stations Wireless defense applications Radar systems

Product Image (3AN-013-0007)

IPEX RF Connector

Price: 35 INR/Piece

Description: RF Conenctor,IPEX ,Coaxial Cable RF Conenctor,IPEX ,Coaxial Cable; High-quality low-loss IPEX rf coaxial connector (also known as MHF/ UFL connector), made according to ROHS standards; Include different models with cable connector and pcb connector for choice; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-013-0001)

IPEX Connector Solder Surface Mount

Price: 30 INR/Piece

Description: RF Conenctor,IPEX ,PCB Mount RF Conenctor,IPEX ,PCB Mount; High-quality low-loss IPEX rf coaxial connector (also known as MHF/ UFL connector), made according to ROHS standards; Include different models with cable connector and pcb connector for choice; From the OEM Original Factory, same quality with much better price.

Product Image (3AN TELECOM)

FAKRA SMB Connector C Type Brown Coax Female Through Hole

Price: 185 INR/Piece

Description: RF Connector,FAKRA Connector,PCB Mount,male,C Type RF Connector,FAKRA Connector,PCB Mount,male,C Type; FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure, color discrimination and misplaced structure to prevent mismatch; Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-023-0004)

FME Connector Jack Crimp Straight Cable Mount Termination

Price: 35 INR/Piece

Description:Female, Straight,Crimp,Cable Mount, Nickel,50,900MHz, RG58/U Features: Female, Straight,Crimp,Cable Mount, Nickel,50,900MHz, RG58/U Offering excellent performance from DC to 200 MHz Low diameter to allow cables it has been installed on to snack through tight access holes or spaces 50 Ohm nominal impedance From the OEM Original Factory, same quality with much better price.

Product Image (3AN-004-0024)

MCX Connector Crimp Type Angled Plug

Price: 60 INR/Piece

Description: Cable Connector, plug/male, Angle/90, 50, RG316, Crimp Type Accessories: Ferrule+ insulator+cover Features: Cable Connector, plug/male, Angle/90, 50, RG316, Crimp Type; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0021)

MCX Connector Crimp Type Female Straight

Price: 75 INR/Piece

Description: Cable Connector, jack/female, Straight/180, 50, RG316, Crimp Type Accessories: pin+ferrule Features: Cable Connector, jack/female, Straight/180, 50, RG316, Crimp Type; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0026)

MCX Bulkhead Connector Straight Female Crimp Type

Price: 45 INR/Piece

Description: Cable Connector, jack/female, Straight/180, 50, RG178,Bulkhead,Crimp Type Accessories: nut+washer+ferrule Features: Cable Connector, jack/female, Straight/180, 50, RG178,Bulkhead,Crimp Type; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-014-0011)

RF Fakra Z Water Blue Male Through Hole PCB Mount

Price: 165 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,50 Ohm,PCB Mount,Through Hole,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,PCB Mount,Through Hole,Brass,Nickel plating; FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-004-0034)

MCX Coax 90 Bulkhead

Price: 65 INR/Piece

Description: Panel Mount,Angled/90,jack/famale,50, Bulkhead Accessories: nut+washer Features: Panel Mount,Angled/90,jack/famale,50, Bulkhead; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-004-0048)

MCX Connector Male Straight Crimp Window Solder

Price: 75 INR/Piece

Description:MCX Connector,Male/Plug,Straight/180,Crimp Window Solder,Gold Plated AccessoriesFerrule Features: MCX Connector,Male/Plug,Straight/180,Crimp Window Solder,Gold Plated; 30% smaller than SMB with same contact and insulator size, make MCX connector lighter and work in smaller space; Snap-on Interface ideal for quick Installation and discount; High cost-effective with excellent boardband performance and low reflections. From the OEM Original Factory, same quality with much better price. Main Application of MCX Connectors: Consumer Electronic: GPS, HDTV, Wireless Internet TV and Audio, smart phone antenna port, Aerospace and Defense: GPS and Hand-held Device Medical: Telemetry Telecommunications: GPS tracking, positioning and navigation devices, Telecommunications networks, Wireless Base Station, Wireless-LAN Data/Communications: Wireless-LAN, Wireless-PAN(bluetooth), Wireless-WAN Industrial: Machine to machine communications

Product Image (3AN-012-0030)

CDIN Connectors Types DIN7/16 Female Nickel Plating Cable Solder

Price: 120 INR/Piece

Description: RF connector,DIN7/16,Female,Straight,Standard,Cable,Solder,Nickel Plating,1/2 cable Features: RF connector,DIN7/16,Female,Straight,Standard,Cable,Solder,Nickel Plating,1/2 cable Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-012-0003)

Connector DIN 7/16 Male Clamp Type For LMR200/300/400

Price: 140 INR/Piece

Description: Cable Connector, plug/male, Straight/180, DIN7/16 Connector, Clamp Type, LMR200/300/400 Features: Cable Connector, plug/male, Straight/180, DIN7/16 Connector, Clamp Type, LMR200/300/400; Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-012-0031)

DIN Connector Solder 1/2 Cable DIN7/16 Male Straight Standar Nickel Plating

Price: 120 INR/Piece

Description:RF connector,DIN7/16,Male,Straight,Standard,Cable,Solder,Nickel Plating,1/2 Cable Features: RF connector,DIN7/16,Male,Straight,Standard,Cable,Solder,Nickel Plating,1/2 Cable Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-003-0059)

F Type Connector Female Bulkhead For PCB Mount

Price: 55 INR/Piece

Description: Pcb Mount, Jack/female, Angled/90, 75, bulkhead Accessories: nut+washer Product features: Pcb Mount, Jack/female, Angled/90, 75, bulkhead; Compact Design for less installation space required; Easy quick connect and disconnect coupling; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0073)

F Type Connector Female Crimp

Price: 65 INR/Piece

Description: F Connector,Jack/female,Straight/180,Crimp Type,Front Bulkhead,Cable RG316,Waterproof Product features: F Connector,Jack/female,Straight/180,Crimp Type,Front Bulkhead,Cable RG316,Waterproof; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0057)

Type Compression Connector Vertical Type Plug For Cable

Price: 45 INR/Piece

Description: Cable Connector, plug/male, Straight/180, 75, Compression Type,RG6 Product features: Cable Connector, plug/male, Straight/180, 75, Compression Type,RG6; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0096)

Crimp Type F Connector Straight Male

Price: 45 INR/Piece

Electrical Characteristics Impedance75 ohm Frequency Range: 0~3Ghz VSWR: Straight type 1.2max / R/A type 1.3max Withstanding Voltage: 500 V rms Working Voltage: 170 V rms Center Contact Resistance 10 m Outer Contact Resistance 5 m Insultation Resistance 1000 m RF Leakage -100dB min @1GHz Mechanical Characteristics Coupling: 3/8-32 thread Cable Retention: 20 lbs min. Durability(mating) 500 cycles Environmental Characteristics Temprature Range: -40C ~ +60C

Product Image (3AN-003-0072)

F Connector Crimp Female Straight Bulkhead

Price: 55 INR/Piece

Description: F Connector,Jack/female,Straight/180,Crimp Type,Front Bulkhead,Cable RG316 Product features: F Connector,Jack/female,Straight/180,Crimp Type,Front Bulkhead,Cable RG316; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0043)

F Connector Crimp Type Angled

Price: 45 INR/Piece

Description: Cable Connector, plug/male, Angled/90, 75, RG179, Crimp Type Accessories: insulator+cover+ferrule Features: Cable Connector, plug/male, Angled/90, 75, RG179, Crimp Type; Great security and tamper protection performance with screw on structure; Simple structure and component to produce F connectors in very competitive price; Less than 30 seconds required for wiring make it really easy to install; Can be visually inspect even after connection; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-003-0061)

F Connector Female 75 Ohm Straight Crimp

Price: 65 INR/Piece

Description: F Connector,Straight/180,75,Cable Connector,Crimp Type,RG174 Accessories: ferrule+nut+washer+Rubber O-ring Product features: F Connector,Straight/180,75,Cable Connector,Crimp Type,RG174; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0076)

F Connector Screw On Female Waterproof Crimp And Bulkhead

Price: 85 INR/Piece

Description: F Connector,Jack/female,Straight/180,Crimp Type,Front Bulkhead,Cable RG316,Waterproof Product features: F Connector,Jack/female,Straight/180,Crimp Type,Front Bulkhead,Cable RG316,Waterproof; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0102)

F RG6 Connector Compression Type

Price: 75 INR/Piece

Description: F Connector,Straight/180,Male Plug,Compression RG6 Cable,75ohm,Brass plating nickel Product features: F Connector,Straight/180,Male Plug,Compression RG6 Cable,75ohm,Brass plating nickel Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0097)

F Type Connector Plug Male Pin Threaded Type

Price: 45 INR/Piece

Description: F Type Connector,Male/Plug,Straight/180,Crimp Type,Coaxial Cable Product features: F Type Connector,Male/Plug,Straight/180,Crimp Type,Coaxial Cable Compact Design for less installation space required; Easy quick connect and disconnect coupling; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0090)

F Type Crimp Connector Female Bulkhead

Price: 70 INR/Piece

Description: F Connector,Jack/female,Straight/180,Front Bulkhead,Crimp Type Product features: F Connector,Jack/female,Straight/180,Front Bulkhead,Crimp Type; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0082)

F Type For RG11 Coaxial Connector Male Straight Connector

Price: 65 INR/Piece

Description:F Connector, Coaxial Connector, Male/Plug, Straight/180, Solder Type,for RG11 Product features: F Connector, Coaxial Connector, Male/Plug, Straight/180, Solder Type,for RG11; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0081)

F Type For RG59 Coaxial Connector Male Straight Connector Solder Type

Price: 30 INR/Piece

Description:F Connector, Coaxial Connector, Male/Plug, Straight/180, Solder Type,for RG59 Product features: F Connector, Coaxial Connector, Male/Plug, Straight/180, Solder Type,for RG59; Compact Design for less installation space required; Easy quick connect and disconnect coupling; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0077)

F Type Male Connector Coaxial Connector Solder Type

Price: 35 INR/Piece

Description:F Connector,Male/Plug, Coaxial Connector, Solder Type, for RG58 Product features: F Connector,Male/Plug, Coaxial Connector, Solder Type, for RG58; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-003-0099)

RF Coaxial Connector F Type Right Angled

Price: 65 INR/Piece

Description: F Type Connector,Male/Plug,Angled/90,Crimp Type,Coaxial Cable Product features: F Type Connector,Male/Plug,Angled/90,Crimp Type,Coaxial Cable Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-014-0040)

Car Radio Stereo Fakra A Male Black Crimp Connector

Price: 130 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,Crimp,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,Crimp,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price. Appliance WLAN GPS PC/LAN Automotive Base Station Head End Equipment Radios Wireless/ Networks Antenna Instrumentation Telecom

Product Image (3AN-014-0027)

Fakra A Connector Female Crimp Solder

Price: 130 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price. Appliance WLAN GPS PC/LAN Automotive Base Station Head End Equipment Radios Wireless/ Networks Antenna Instrumentation Telecom

Product Image (3AN-014-0007)

Fakra Connectors H Female Solder

Price: 145 INR/Piece

Description: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG316,RG174 ,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG316,RG174 ,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price. Appliance WLAN GPS PC/LAN Automotive Base Station Head End Equipment Radios Wireless/ Networks Antenna Instrumentation Telecom

Product Image (3AN-014-0034)

Fakra B Connector Fakra SMB Male PCB Mount Plug Straight End Launch Beige Bluetooth RF Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Straight,Male,Plate Edge,PCB mount,Brass,Nickel plating Features: RF Connector,Fakra Connector,Straight,Male,Plate Edge,PCB mount,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price. Appliance WLAN GPS PC/LAN Automotive Base Station Head End Equipment Radios Wireless/ Networks Antenna Instrumentation Telecom

Product Image (3AN-014-0004)

Fakra C Connector Male Blue Through Hole PCB Right Angle

Price: 140 INR/Piece

Description: RF Connector,Fakra Connector,Male,right angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,right angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0018)

Fakra Coax Connector Car TV Fakra F Female Brown Crimp Solder Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG316 RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG316 RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price

Product Image (3AN-014-0008)

Fakra Connector Codes Car Stereo Satellite Radio Fakra H Male Pink Crimp Solder Connector

Price: 140 INR/Piece

Description: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Crimp,Solder,for Cable,RG316,RG174,Brass,Nickel platingng Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Crimp,Solder,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0015)

Fakra Connector Connection Fakra B Female Crimp Solder

Price: 155 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Crimp,Solder,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Crimp,Solder,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0017)

Fakra Connector Crimp Fakra B Female Right Angle White Solder

Price: 130 INR/Piece

Description:RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Solder,Crimp,for Cable,RG174,RG316,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Solder,Crimp,for Cable,RG174,RG316,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0020)

Fakra Connector Female Fakra A Right Angle Black Crimp Solder Connector

Price: 130 INR/Piece

Description:RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Solder,Crimp,for Cable,RG174,RG316,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Solder,Crimp,for Cable,RG174,RG316,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0028)

Fakra Connector Frequency F Female Crimp Solder

Price: 130 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58 LMR-195 RG400 RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0036)

Fakra Connector GPS Male PCB Mount Plug End Launch Car Straight Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,Plate Edge,PCB mount,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,Plate Edge,PCB mount,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0039)

Fakra Connector Market K Female Crimp Solder

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,for Cable,RG58,LMR-195,RG400 RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,for Cable,RG58,LMR-195,RG400 RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0037)

Fakra Connector Pins Fakra SMB C Blue Male Right Angle PCB Mount Solder Coaxial Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Male,Right Angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Right Angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0005)

Fakra Connector Types Z Female Crimp Solder

Price: 120 INR/Piece

Description: RF Connector,Fakra Connector,Female,right angle,Solder,Crimp,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,right angle,Solder,Crimp,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch; Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0030)

Fakra Connector White Plug Male End Launch PCB Mount RF Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,50 Ohm,Plate Edge,PCB mount,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Plate Edge,PCB mount,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0023)

Fakra D Female Right Angle Claret Violet Crimp Connector

Price: 130 INR/Piece

Description:RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Crimp,for Cable, RG174 RG316,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Crimp,for Cable, RG174 RG316,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0008)

Fakra E Connector Car TV Female Green Crimp Solder Connector

Price: 150 INR/Piece

Description: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable, RG316,RG174 ,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable, RG316,RG174 ,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0044)

Fakra E Female Right Angle Green Crimp Connector

Price: 155 INR/Piece

Description:RF Connector,Fakra Connector,Female,Right Angle,Crimp,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Right Angle,Crimp,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0026)

Fakra Female Connector C Crimp Solder

Price: 160 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG400,RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG400,RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0022)

Fakra Female E Crimp Solder RG58 LMR-195 RG400 RG142 Cable Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Solder,Crimp,for Cable,RG58,LMR-195,RG400,RG142,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0010)

Fakra I Female Crimp Solder

Price: 145 INR/Piece

Description: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Crimp,Solder,for Cable,RG58,LMR-195,RG400,RG142,Cable,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Crimp,Solder,for Cable,RG58,LMR-195,RG400,RG142,Cable,Brass,Nickel plating; FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0019)

Fakra Jack Connector Fakra K Male Curry RG316 RG174 Cable Crimp Connector For Car Sirius XM Radio

Price: 175 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,50 Ohm,Crimp,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Crimp,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0001)

FAKRA Male Connector C Type Blue Plug Through Hole PCB Mount

Price: 145 INR/Piece

Description: RF Connector, FAKRA Connector, PCB Mount, C Type, plug/male, Through Hole RF Connector, FAKRA Connector, PCB Mount, C Type, plug/male, Through Hole; FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure, color discrimination and misplaced structure to prevent mismatch; Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0021)

Fakra Male Connector Car Telematics Fakra D Claret Violet Crimp Connector For RG316 RG174 Cable

Price: 165 INR/Piece

RF Connector,Fakra Connector,,Male,Straight,50 Ohm,Crimp,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0044)

Fakra Male SMB Female Car Radio Stereo Fakra A Black Crimp Connector For RG174 RG316 Cable

Price: 175 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,Crimp,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,Crimp,for Cable,RG316,RG174,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0014)

Fakra Plastic Connector Fakra C Female Right Angle Blue Crimp Solder Connector For RG174 RG316 Cable

Price: 160 INR/Piece

Description:RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Solder,Crimp,for Cable,RG174,RG316,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Right Angle,50 Ohm,Solder,Crimp,for Cable,RG174,RG316,Brass,Nickel plating; FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0035)

Fakra Purple Connector Fakra D SMB Plug PCB Mount Angled Male RF Connector Purple

Price: 155 INR/Piece

Description:RF Connector,Fakra Connector,Male,Right Angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Right Angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0015)

Fakra RF Connectors Car Radio Stereo Fakra A Female Black Crimp Connector

Price: 165 INR/Piece

Description:RF Connector,Fakra Connector,Female,Straight,50 Ohm,Crimp,for Cable,RG316RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Female,Straight,50 Ohm,Crimp,for Cable,RG316RG174,Brass,Nickel plating; FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0006)

Fakra SMB Connector C Male Blue Right Angle Through Hole PCB Connector

Price: 145 INR/Piece

Description:RF Connector,Fakra Connector,SMB,Male,right angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating Features: RF Connector,Fakra Connector,SMB,Male,right angle,50 Ohm,PCB mount,Through Hole,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0003)

FAKRA SMB Connector C Type Brown Coax Male Through Hole

Price: 135 INR/Piece

Description: RF Connector, FAKRA Connector, PCB Mount, male, E Type, Green RF Connector, FAKRA Connector, PCB Mount, male, E Type, Green; FAKRA rf coax circular connector, designed for automotive industry. With secondary locking structure, color discrimination and misplaced structure to prevent mismatch; Safe and fully automatic assembly system to ensure the competitive price and high efficiency. Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0025)

Fakra Z Connector Male Water Blue Crimp Solder Connector

Price: 165 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,50 Ohm,Solder,Crimp,for Cable,RG174,RG316C,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Solder,Crimp,for Cable,RG174,RG316C,Brass,Nickel plating FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-014-0012)

Fakra Z Dual Male Water Blue Solder Car Antenna Connector

Price: 230 INR/Piece

Description:RF Connector,Fakra Connector,Male,Straight,50 Ohm,Solder,for Cable,RG316,RG174,Brass,Nickel plating Features: RF Connector,Fakra Connector,Male,Straight,50 Ohm,Solder,for Cable,RG316,RG174,Brass,Nickel plating; FAKRA rf coax circular connector, designed for automotive industry With secondary locking structure 14 different mechanical and color codes discrimination and misplaced structure to prevent mismatch Safe and fully automatic assembly system to ensure the competitive price and high efficiency Achieve the ROHS standard; Widely used in car navigation systems, remote control systems, car TV, audio equipment, antenna and so on; From the OEM Original Factory, same quality with much better price.

Product Image (3AN-012-0026)

7/16 Clamp Connector Straight Type Nickel Plating For RG393 Cable

Price: 80 INR/Piece

Description:male,straight,standard,50ohm,cabl,solder cup,clamp,RG393,copper,nickel plating Features: male,straight,standard,50ohm,cabl,solder cup,clamp,RG393,copper,nickel plating Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-012-0016)

7/16 Connector Plug 50 Cable Mount Clamp Termination

Price: 150 INR/Piece

Description:Male,Straight, Clamp,Cable Mount,Nickel,50,6GHz Features: Male,Straight, Clamp,Cable Mount,Nickel,50,6GHz Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-012-0032)

RF Termination Loads DIN Male Connector Load Straight

Price: 150 INR/Piece

Description:Male,Connector,load,Straight,RF Termination loads DIN Features: Male,Connector,load,Straight,RF Termination loads DIN Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-012-0001)

7/16 Male DIN Connector Angled Crimp Type For Cable

Price: 130 INR/Piece

Description: Cable Connector, plug/male, Angled/90, DIN7/16 Connector, Crimp Type Accessories: insulator+ferrule+cover Features: Cable Connector, plug/male, Angled/90, DIN7/16 Connector, Crimp Type; Designed to minimize signal distortion from inter modulation; Screw on coupling ensure high durability and allow toolless application; Excellent performance up to 5.2GHz frequency. From the OEM Original Factory, same quality with much better price. Main Application of DIN7/16 Connectors: Consumer Electronic: Statellite Receivers, Statellite Radio Aerospace and Defense: High-power communication devices Commercial Vehicle: Bluetooth Telecommunications: Antenna, Base Station Industriasl: Antenna Mounts, Machine to Machine Communications

Product Image (3AN-010-0001)

DIN 1.0/2.3 Connector Straight Male Crimp Type For Cable RG174

Price: 85 INR/Piece

Description: Cable Connector, plug/male, Straight/180, RG174,DIN1.0/2.3, Crimp Type Accessories: pin + ferrule Features: Cable Connector, plug/male, Straight/180, RG174,DIN1.0/2.3, Crimp Type; Compact design is ideal for limit space application and save space in delivery; Push/pull mating is excellent for quick installation without vibrate loose; Great performance with frequency up to 10GHz support high data rates. From the OEM Original Factory, same quality with much better price. Main Application of DIN1.0/2.3 Connectors: Aerospace and Defense: Communication systems Telecommunications: CATV, Central office, High-density Radios, Base station, Switching equipment Networking: Video Equipment, Radio boards

Product Image (3AN-001-0167)

BNC Male Connector Clamp Coaxial Cables

Price: 60 INR/Piece

Electrical Characteristics Impedance50ohm Frequency Range: 0~1 GHz for 75 ohm VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0284)

Female BNC Straight Rear Bulkhead Solder Type

Price: 45 INR/Piece

Description:BNC Connector,Female,Straight,50Ohm,Solder Type,Nikel Plating Product features: BNC Connector,Female,Straight,50Ohm,Solder Type,Nikel Plating; Compact Design for less installation space required; Easy quick connect and disconnect coupling; From the OEM Original Factory, same quality with much better price. Appliance: Consumer Electronic: Statellite Boxes, set top boxes Telecommunications: CATV, CATV Networks.

Product Image (3AN-001-0253)

BNC Connector Crimp Female For Cable

Price: 55 INR/Piece

Electrical Characteristics Impedance50ohm Frequency Range: MALEVSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0092)

Right Angle BNC Connector Plug For Cable RG178

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0145)

BNC Bulkhead Female Coaxial Connector Crimp Type For Cable

Price: 40 INR/Piece

Electrical Characteristics Impedance50ohm Frequency Range: 0~1 GHz for 75 ohm VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-010-0017)

1.0/2.3 Connector Plug Crimp Straight 75 Termination Cable Mount Miniature Bulkhead Fitting Snap-On

Price: 55 INR/Piece

Description: Male,Straight,Crimp, Cable Mount,Brass,Nickel, Miniature,75,Snap-On,3GHz,Bulkhead Accessories:pin+ferrule Features: Male,Straight,Crimp, Cable Mount,Brass,Nickel, Miniature,75,Snap-On,3GHz,Bulkhead Compact design is ideal for limit space application and save space in delivery; Push/pull mating is excellent for quick installation without vibrate loose; Great performance with frequency up to 10GHz support high data rates. From the OEM Original Factory, same quality with much better price. Main Application of DIN1.0/2.3 Connectors: Aerospace and Defense: Communication systems Telecommunications: CATV, Central office, High-density Radios, Base station, Switching equipment Networking: Video Equipment, Radio boards

Product Image (3AN-010-0015)

1.0/2.3 Connector Straight 75 Plug Crimp Termination Miniature Bulkhead Fitting Snap-On For Cable Mount

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m Mechanical Characteristics Coupling: Push-pull Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +155C

Product Image (3AN-001-0072)

1.0/2.3 Connector Straight 75 Plug Solder Termination For Cable Mount

Price: 95 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m Mechanical Characteristics Coupling: Push-pull Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +155C

Product Image (3AN-010-0026)

DIN 1.0 2.3 Connector Right Angle Female DIP Type Bulkhead Panel Mount

Price: 55 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m Mechanical Characteristics Coupling: Push-pull Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +155C

Product Image (3AN-010-0011)

DIN 1.0/2.3 Connector Right Angle Male Crimp Type For Coaxial Connector

Price: 65 INR/Piece

Description: DIN1.0/2.3,Male/Plug,Right Angled/90,Crimp Type,Coaxial Cable Accessories:dustproof cap+ferrule Features: DIN1.0/2.3,Male/Plug,Right Angled/90,Crimp Type,Coaxial Cable; Compact design is ideal for limit space application and save space in delivery; Push/pull mating is excellent for quick installation without vibrate loose; Great performance with frequency up to 10GHz support high data rates. From the OEM Original Factory, same quality with much better price. Main Application of DIN1.0/2.3 Connectors: Aerospace and Defense: Communication systems Telecommunications: CATV, Central office, High-density Radios, Base station, Switching equipment Networking: Video Equipment, Radio boards

Product Image (3AN-010-0006)

DIN 1.0/2.3 Connector Straight Male Crimp Type For Cable RG316-RG174

Price: 75 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~6 VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m

Product Image (3AN-010-0007)

DIN 1.0/2.3 Male Straight Connector Crimp For 1855A Cable

Price: 85 INR/Piece

Description: DIN1.0/2.3,Cable Connector,male/plug,Straight/180,Crimp Type DIN1.0/2.3,Cable Connector,male/plug,Straight/180,Crimp Type ; Compact design is ideal for limit space application and save space in delivery; Push/pull mating is excellent for quick installation without vibrate loose; Great performance with frequency up to 10GHz support high data rates. From the OEM Original Factory, same quality with much better price. Main Application of DIN1.0/2.3 Connectors: Aerospace and Defense: Communication systems Telecommunications: CATV, Central office, High-density Radios, Base station, Switching equipment Networking: Video Equipment, Radio boards

Product Image (3AN-010-0008)

DIN 1.0/2.3 R/A Male Connector Crimp Type For Cable RG179

Price: 85 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~6 VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 500V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m

Product Image (3AN-010-0002)

DIN Coax Connector 1.0/2.3 Angled Plug Crimp Type For Cable

Price: 65 INR/Piece

Description: Cable Connector, plug/male, Angled/90, DIN1.0/2.3, Crimp Type Accessories: insulator + ferrule + cover Features: Cable Connector, plug/male, Angled/90, DIN1.0/2.3, Crimp Type; Compact design is ideal for limit space application and save space in delivery; Push/pull mating is excellent for quick installation without vibrate loose; Great performance with frequency up to 10GHz support high data rates. High Quality with 30 days 100% Money back; From the OEM Original Factory, same quality with much better price. Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m

Product Image (3AN-010-0023)

DIN Type Connector Female Straight Glod Plating Bulkhead For PCB Mount

Price: 80 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m

Product Image (3AN-010-0009)

DIN1 .0 2.3 Connector Female Right Angled Through Hole For PCB Mount

Price: 80 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~6 VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 500V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m Mechanical Characteristics Coupling: Push-pull Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -65C ~ +165C

Product Image (3AN-010-0005)

DIN 1.0/2.3 Coaxial Connectors R/A Gold Plated Jack PCB Mount Connector

Price: 80 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m Mechanical Characteristics Coupling: Push-pull Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +155C

Product Image (3AN-001-0157)

BNC Straight Plug Connector Crimp Type For Coaxial Cable

Price: 35 INR/Piece

Electrical Characteristics Impedance50ohm Frequency Range: 0~1 GHz for 75 ohm VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0048)

BNC Connector 50 Ohm Angled Jack White Plastic PCB Mount

Price: 60 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0047)

BNC Connector 50 Ohm Straight Jack With ABS Housing

Price: 55 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101 Material: Part Material Finish Body Zinc Nickel Center Contact Pin Brass Au Insulator POM White

Product Image (3AN-201-2298)

BNC Bulkhead 75 Ohm Connector Angled Jack PCB Mount

Price: 55 INR/Piece

Electrical Characteristics Impedance75 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101 Material: Part Material Finish Body Zinc Tinning Center Contact Pin Brass Gold Insulator POM White

Product Image (3AN-001-0061)

BNC Connector Wall Mount 4 Hole Square Flange Jack

Price: 85 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-010-0023)

1.0/2.3 Connector Plug Crimp Straight 75 Termination Cable Mount Standard 6GHz

Price: 80 INR/Piece

Electrical Characteristics Impedance50 ohm or 75 ohm Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm VSWR: Straight type 1.3max / R/A type 1.5max Dielectric Withstanding Voltage: 750 V rms Working Voltage: 250 V rms Center Contact Resistance 6.0 m (Milliohms max.) Outer Contact Resistance 3.0 m (Milliohms max.) Insultation Resistance 10 m Mechanical Characteristics Coupling: Push-pull Contact Retention: 4 lbs min. Mating Durability: 500 cycles (For Beryllium Copper Contact) Environmental Characteristics Environmental Characteristics: -40C ~ +155C

Product Image (3AN-001-0077)

BNC Connector RG179 Straight Male Crimp Type

Price: 70 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance75 ohm Frequency Range: 0~3 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0076)

BNC Connector For RG59 Crimp Type Plug Straight

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101 Material: Part Material Finish Body Brass Nickel (Ni) Center Contact Pin Brass Gold Insulator Delrin Natural

Product Image (3AN-001-0071)

BNC Connector For RG174 Straight Crimp Type Male

Price: 45 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles

Product Image (3AN-001-0290 )

BNC Connector Male Right Angle 50 Cable Mount Plug Nickel Clamp Termination RG58 C/U

Price: 60 INR/Piece

Impedance50ohm Frequency Range: 0~1 GHz for 75 ohm VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0171)

BNC Connector Male Type Clamp Cable

Price: 60 INR/Piece

Electrical Characteristics Impedance50ohm Frequency Range: 0~1 GHz for 75 ohm VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0093)

BNC Connector Plug Angled For Cable RG316

Price: 35 INR/Piece

Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles

Product Image (3AN-001-0067)

BNC Connector RG59 Crimp Type Straight Jack Panel Mount

Price: 65 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min.

Product Image (3AN-001-0063)

BNC Connector To Coaxial Cable Bulkhead Straight Female

Price: 35 INR/Piece

Techinial Datasheet: Electrical Characteristics Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.)

Product Image (3AN-001-0138)

BNC Female Bulkhead Coaxial Connector Right Angle Through Hole For PCB Mount

Price: 55 INR/Piece

Electrical Characteristics Impedance50ohm Frequency Range: 0~1 GHz for 75 ohm VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 103 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55~+155 / POM -40~+60 Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

Product Image (3AN-001-0075)

BNC Male Connector 50 Ohm Straight Clamp Type

Price: 45 INR/Piece

Impedance50 ohm Frequency Range: 0~4 GHz VSWR: Straight type 1.22/3GHz / R/A type 1.30/3GHz Dielectric Withstanding Voltage: 1500 V rms Working Voltage: 500 V rms Center Contact Resistance 1.5 m (Milliohms max.) Outer Contact Resistance 2.0 m (Milliohms max.) Insultation Resistance 5 10 m (Milliohms min.) Mechanical Characteristics Coupling: bayonet Contact Retention: 6 lbs min. Mating Durability: 500 cycles Environmental Characteristics Environmental Characteristics: Teflon -55oC~+155oC / POM -40oC~+60oC Coupling Nut Retention: 100 lbs. min. Vibration: MIL-STD-202 Meth. 204 Corrosion Resistance: MIL-STD-202 Meth. 101

X


Back to top
