2.4GHz Wi-Fi WLAN RP-SMA Omni Antenna With IPX U.FL To RP-SMA Cable 15cm

2.4GHz Wi-Fi WLAN RP-SMA Omni Antenna With IPX U.FL To RP-SMA Cable 15cm Specification

Conductor Type
Inner Core

Operating Temperature
-20°C to +65°C

Rated Temperature
-20°C to +65°C

Features
2.4GHz omnidirectional Wi-Fi antenna, suitable for WLAN devices, stable signal reception, detachable design, high gain, low loss cable, wide compatibility

Insulation
PTFE

Diameter
Antenna: 10mm

Core Number
1

Impedance
50 Ohms

Locking Type
Screw-threaded RP-SMA connector

Number of Conductor
1

Core Material
Copper

Install Type
External mount

Usage & Applications
Wireless LAN, Wi-Fi projects, IoT devices, embedded modules

Conductor Shape
Stranded

Tensile Strength
Standard for flexible RF cables

Weight
~9g (Antenna + Cable)

Cable Type
Coaxial

Product Type
2.4GHz Wi-Fi RP-SMA omnidirectional antenna with IPX U.FL to RP-SMA cable

Length
Antenna length: ~11cm; Cable length: 15cm

Voltage
N/A (Passive device)

Insulation Material
PTFE

Application
Wi-Fi routers, wireless adapters, embedded wireless modules, ESP32/ESP8266 boards, IoT devices

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-40°C to +80°C

Connector Color
Gold/Black

Shield Material
Copper

Jacket Color
Black

Dimension (L*W*H)
Cable: 150mm (L); Antenna: 110mm (L) x 10mm (Dia)

Color
Black

Material
Brass, Copper, ABS Plastic

Size
Antenna: 110mm; Cable: 150mm

Operating Humidity
5%~95% (non-condensing)

Antenna Type
Rubber Duck

VSWR
2.0

Radiation
Omni-directional

Mounting Method
Direct screw-on to RP-SMA ports

Brand Compatibility
Universal for devices with RP-SMA female and U.FL/IPX interface

Polarization
Linear, Vertical

Return Loss
-10dB (at 2.4GHz)

Cable Grade
1.13mm Mini Coaxial

Waterproof
No (indoor use)

RoHS Compliance
Yes

Frequency Range
2400 - 2500 MHz

Cable Impedance
50 Ohm

Connector Type
RP-SMA Male (Antenna), U.FL/IPX (Cable)

Gain
3dBi

2.4GHz Wi-Fi WLAN RP-SMA Omni Antenna With IPX U.FL To RP-SMA Cable 15cm Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About 2.4GHz Wi-Fi WLAN RP-SMA Omni Antenna With IPX U.FL To RP-SMA Cable 15cm

Description:Omnidirectional Antenna,Indoor Antenna,ExternalAntenna,Rubber Duck Antenna,Vertical Antenna,2.4G Antenna,3dBi,50Ohm,WiFi/WLAN,Threaded,Plug,Straight,Reverse

Omnidirectional Antenna,Indoor Antenna,External Antenna,Rubber Duck Antenna,Vertical Antenna,2.4G Antenna,3dBi,50Ohm,WiFi/WLAN,Threaded,Plug,Straight,Reverse
Used to transmit and receive electromagnetic wave in Wireless deverice with stable signal and low loss;
Applied to wireless communication, radio, TV, radar, remote control fields;
Multi mode and specification for choice;
From the OEM Original Factory, same quality with much better price.

Reliable Signal Enhancement

Boost your wireless signal with this 2.4GHz omni-directional antenna, featuring a linear vertical polarization and 3dBi gain. The design is tailored to provide stable and consistent Wi-Fi performance for routers, adapters, and IoT devices in indoor environments.

Wide Compatibility and Flexible Use

Compatible with any device sporting an RP-SMA female port or U.FL/IPX interface, this antenna suits a range of applicationsfrom ESP32/ESP8266 development boards to embedded wireless modules in smart home or industrial IoT projects.

Easy Installation and Durable Build

The antenna connects easily using a screw-threaded RP-SMA connector and detachable cable. Built with robust copper and ABS plastic, its flexible coaxial cable ensures durability, while RoHS compliance supports safe and responsible usage.

FAQs of 2.4GHz Wi-Fi WLAN RP-SMA Omni Antenna With IPX U.FL To RP-SMA Cable 15cm:

Q: How do I install the 2.4GHz WLAN RP-SMA Omni Antenna with IPX U.FL to RP-SMA cable?

A: Installation is straightforward: screw the RP-SMA male connector directly onto a matching RP-SMA female port on your device. If using the U.FL/IPX interface, carefully connect the cables U.FL female end to your module. No tools or power supply are needed as this is a passive device.

Q: What devices are compatible with this antenna and adapter cable?

A: This antenna and 15cm adapter cable are universally compatible with devices featuring RP-SMA female ports or U.FL/IPX connectors, such as Wi-Fi routers, USB Wi-Fi adapters, embedded wireless modules, ESP32/ESP8266 development boards, and a variety of IoT and WLAN equipment.

Q: When should I consider using this omnidirectional antenna for my Wi-Fi projects?

A: Consider this antenna whenever you need to improve wireless coverage, signal quality, or stability in indoor environments for projects involving Wi-Fi or IoT modules where space is limited and adaptable mounting is desired.

Q: Where can this antenna be used?

A: This antenna is intended for indoor use, such as homes, offices, laboratories, and development environments. It is not waterproof, so avoid outdoor or wet locations to prevent damage and maintain optimal performance.

Q: What is the proper process to safely connect and disconnect the U.FL/IPX connector?

A: To connect, gently align the U.FL/IPX connector with the modules port and press until it snaps in place. To disconnect, use a small tool or fingernail to lift the connector straight up, avoiding sideways pressure to protect the socket and cable integrity.

Q: How does this antenna benefit my wireless LAN or IoT device?

A: This antenna provides an improved, omnidirectional reception pattern with 3dBi gain and low loss, enabling more stable connections, wider coverage, and fewer dead spots for Wi-Fi or IoT applications in indoor conditions.
