Send InquiryBuy SMB Connector Straight Plug Crimp Type For RG316
Buy SMB Connector Straight Plug Crimp Type For RG316 Specification
- Impedance
- 50 Ohm
- Features
- Secure snap-on coupling, compact size, low RF leakage, reliable signal transmission
- Locking Type
- Snap-on
- Rated Temperature
- -55C to +155C
- Number of Conductor
- 1
- Tensile Strength
- >15N
- Dielectiric Strength
- AC 1000V/Minute
- Operating Temperature
- -65C to +165C
- Core Material
- Copper
- Cable Type
- RG316
- Conductor Shape
- Round
- Conductor Type
- Single core
- Diameter
- 6mm
- Weight
- Approx 3g
- Insulation
- PTFE
- Armored Material
- Not Armored
- Usage & Applications
- Suitable for flexible coaxial cable connections in radio frequency circuits
- Install Type
- Crimp Type
- Core Number
- Single core
- Product Type
- SMB Connector Straight Plug Crimp Type
- Length
- As per cable requirement
- Voltage
- 335 V RMS max
- Insulation Material
- PTFE
- Application
- RF applications, communication equipment, test instruments, GPS, telecom
- Conductor Material
- Copper
- Jacket Material
- PVC
- Storage Temperature
- -40C to +85C
- Connector Color
- Gold
- Shield Material
- Copper alloy (gold plated)
- Jacket Color
- Standard
- Dimension (L*W*H)
- Approx 25mm (L), 6mm (D)
- Material
- Brass (gold-plated)
- Color
- Gold
- Size
- Standard for RG316
- Packaging
- Bulk/Individual Pack
- Contact Plating
- Gold over nickel
- Frequency Range
- DC to 4 GHz
- Standards Compliance
- MIL-C-39012, IEC 61169-10
- Insulation Resistance
- 1000 M
- Mating Cycles
- 500 cycles
- Contact Resistance
- Center contact 6m, Outer contact 1m
- Gender
- Plug (Male)
- Surface Finish
- Gold-plated body and contacts
- Crimp Size
- Outer ferrule: 3.3mm, Inner pin: 1.1mm
- Cable Compatibility
- RG316, RG174
- VSWR
- 1.30
Buy SMB Connector Straight Plug Crimp Type For RG316 Trade Information
- Minimum Order Quantity
- 5 Pieces
- Main Domestic Market
- All India
Buy SMB Connector Straight Plug Crimp Type For RG316 About
Description: plug/male, straight/180, 50,Cableconnector,RG316
Accessories: Ferrule
Features:
- plug/male, straight/180, 50,Cable connector,RG316;
- Snap-on coupling design for fast installation;
- With boardband performance and low reflection;
- To reduce your Cost by using die casting process in non-critical areas.
- From the OEM Original Factory, same quality with much better price.
Main Application of SMB Connectors:
Aerospace and Defense: Test Stands
Medical: Telemetry
Commercial Vehicle: GPS
Telecommunications: Wireless Base Stations, Cellular Mobile System
Data/Communications: Routers, WIFI, Radio Boards
Industrial: M2M Communications, Process Controls, Video Systems,Instrumentation
Superior Signal Integrity and Reliability
Designed for stable RF signal transmission, this SMB connector maintains low contact resistance and high insulation resistance, ensuring minimal loss and robust connectivity. The gold-plated contacts and body further enhance conductivity and corrosion resistance, resulting in reliable performance across diverse environments and applications.
Versatile Compatibility and Application
Compatible with RG316 and RG174 cables, the connector suits flexible coaxial cable connections in radios, GPS, test instruments, and telecom setups. Its crimp type installation and snap-on locking mechanism make it easy to install and secure, supporting frequent mating cycles with consistent performance.
Adhering to International Standards
Manufactured in compliance with MIL-C-39012 and IEC 61169-10, this SMB straight plug ensures high quality and reliability for demanding RF applications. Its design and build quality are validated by international guidelines, making it a trustworthy choice for manufacturers, exporters, suppliers, and wholesalers in India and beyond.
FAQs of Buy SMB Connector Straight Plug Crimp Type For RG316:
Q: How do I install the SMB Connector Straight Plug Crimp Type for RG316 cables?
A: To install, insert the stripped RG316 or RG174 cable into the connector, crimp the inner pin and outer ferrule using the correct size tools (1.1mm inner pin, 3.3mm outer ferrule), and secure the snap-on coupling for reliable attachment.Q: What applications are suitable for this SMB connector?
A: This connector is ideal for RF applications including communication equipment, test instruments, GPS systems, and telecom installations, thanks to its low RF leakage and stable signal transmission.Q: When should I choose this SMB crimp type connector over other types?
A: Select this crimp type SMB connector when you need strong mechanical retention, compact size, quick snap-on coupling, and reliable performance in environments demanding frequent connections and reconnections.Q: Where can this connector be used besides typical RF circuits?
A: Besides standard RF circuits, this connector finds use in laboratory test setups, mobile communication devices, and GPS modules where dependable and high-frequency signal transfer is essential.Q: What benefits does the gold-plated finish offer?
A: The gold-plated contacts enhance conductivity and prevent corrosion, ensuring low contact resistance and longer connector life, especially in challenging environmental conditions.Q: How does the connector comply with safety and quality standards?
A: Manufactured to MIL-C-39012 and IEC 61169-10 standards, and tested for electrical, mechanical, and environmental reliability, the connector guarantees safe and consistent performance under rigorous conditions.Q: What is the process for bulk or individual packaging?
A: Connectors are supplied either in bulk quantities for large-scale requirements or individually packed for easy identification and secure handling, providing flexibility for manufacturers, suppliers, exporters, and wholesalers.Price 75 INR/ Piece
