Coaxial RF Cable SMA Female Straight Front Bulkhead To MCX Male

Coaxial RF Cable SMA Female Straight Front Bulkhead To MCX Male Specification

Product Type
Coaxial RF Cable

Number of Conductor
Single

Conductor Diameter
Approx. 1.13mm (customizable)

Conductor Number
1

Armored Material
No Armored Layer

Jelly Filled
No

Rip Cord
No

Insulation
PTFE/PE

Installation Guideline
Suitable for RF Signal Transmission

Jacket
PVC or LSZH

Pairs
Single Pair

Color
Black or as specified

No Of Pairs
1

No Of Core
1

Heat Proof
Yes

Length
Custom as per requirement

Connector 1 Type
SMA Female Straight Front Bulkhead

Cable Type
Flexible Coaxial

Cable Impedance
50 Ohms

Connector 2 Type
MCX Male

Shielding
Single or Double Shielded (Braid + Foil)

Application
RF Communication, Antenna Connection, Wireless Systems, GPS

VSWR
1.3:1 max

Operating Temperature
-40C to +85C

Return Loss
>=22 dB (typical, depending on frequency)

Frequency Range
DC to 6 GHz

Voltage Rating
Up to 335V RMS

RoHS Compliant
Yes

Coaxial RF Cable SMA Female Straight Front Bulkhead To MCX Male Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

Coaxial RF Cable SMA Female Straight Front Bulkhead To MCX Male About

Description:RF Coaxial Cable,SMA Female,MCX Male,CableAssembly

RF Coaxial Cable,SMA Female,MCX Male,Cable Assembly;
Used for Wireless communication and Wireless LAN;
Application include Mobile Phone, PC, GPS, Network Storage Equipment, Medical, Lighting, Remote Control, etc;
Pre-assemblied with different RF connectors for choice. Size and cable length can be customized;
From the OEM Original Factory, same quality with much better price.

Reliable Signal Transmission for RF Applications

Designed for demanding environments, this coaxial RF cable ensures consistent and high-quality signal transmission. With options for single or double shielding and a minimized VSWR of 1.3:1, it meets stringent communication standards. The custom length and flexible build fit diverse installation needs, while the operating temperature range of -40C to +85C ensures performance in extreme conditions.

Versatile Connectivity and Custom Options

Whether connecting antennas, GPS devices, or wireless equipment, the SMA Female Straight Front Bulkhead and MCX Male connectors provide secure, efficient interfaces. Custom conductor diameters, lengths, and color options make this cable suitable for varied applications, with easy integration into RF systems, communication infrastructure, and testing environments.

FAQs of Coaxial RF Cable SMA Female Straight Front Bulkhead To MCX Male:

Q: How do I install the Coaxial RF Cable with SMA Female and MCX Male connectors?

A: Installation is straightforward. Simply secure the SMA Female Straight Front Bulkhead connector to the panel or chassis, and attach the MCX Male connector to your device. Ensure the cable is routed away from sources of interference to maintain optimal performance.

Q: What is the recommended usage of this RF cable?

A: This cable is designed for RF signal transmission in communication systems, antenna connections, wireless networks, and GPS installations. Its 50-ohm impedance and robust shielding make it ideal for high-frequency signal applications up to 6 GHz.

Q: When should I opt for single versus double shielding in this coaxial cable?

A: Single shielding is sufficient for most standard installations. However, if your environment is prone to high EMI/RFI interference, double shielding (braid and foil) provides enhanced protection against signal degradation.

Q: Where can this cable be used in my equipment setup?

A: Its suitable for internal or external RF connections in base stations, routers, GPS receivers, wireless modules, and antenna systems. Its front bulkhead configuration also allows secure mounting through enclosures or panels.

Q: What are the benefits of using a custom-length cable for my RF system?

A: Custom lengths help eliminate excess cable, reduce signal loss, and improve installation neatness and efficiency. Tailoring the cable size ensures optimal performance specific to your equipment layout.

Q: How does the cables construction support heat resistance?
