F Connector Female 75 Ohm Straight Crimp

F Connector Female 75 Ohm Straight Crimp Specification

Diameter
Outer shell: ~9.5 mm

Core Material
Brass

Rated Temperature
-40C ~ +85C

Install Type
Crimp type

Locking Type
Threaded coupling

Weight
Approx. 6 g/unit

Operating Temperature
-40C to +85C

Dielectiric Strength
Standard for RF connectors

Number of Conductor
1

Core Number
Single core

Conductor Shape
Round

Usage & Applications
RF signal transmission, TV, satellite, broadband

Conductor Type
Solid

Features
High quality, corrosion resistant, easy installation, provides secure connection, suitable for outdoor or indoor use

Insulation
PTFE

Tensile Strength
Standard, suitable for cable applications

Impedance
75 Ohm

Cable Type
Coaxial RG6/U, RG59/U or similar

Product Type
F Connector Female 75 Ohm Straight Crimp

Length
Customizable, depends on cable used

Voltage
Rated for standard signal transmission (not for high voltage)

Insulation Material
PTFE (Polytetrafluoroethylene)

Conductor Material
Brass

Jacket Material
Nickel plated brass

Storage Temperature
-55C ~ +125C

Connector Color
Metallic silver

Shield Material
Brass, nickel plated

Jacket Color
Silver

Dimension (L*W*H)
Custom as per model, typical length approx. 20 mm

Color
Silver

Material
Nickel plated brass

Size
F-type standard size (Outer shell: ~9.5 mm diameter)

Crimp Type
Hex crimp for cable

Packaging
Bulk or as per order

RoHS Compliant
Yes

Connector Gender
Female

Mounting Type
Cable mount (in-line)

VSWR
1.3 max

Center Pin Material
Gold plated brass

Frequency Range
DC to 3 GHz

Contact Plating
Nickel

Resistant to
Moisture, oxidation

F Connector Female 75 Ohm Straight Crimp Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About F Connector Female 75 Ohm Straight Crimp

Buy online the finest F Connector Female 75 Ohm Straight Crimp at the lowest pricelimited stock available! This unparalleled connector features lustrous nickel-plated brass for the outer shell and gold-plated brass for the center pin, ensuring corrosion resistance and optimal signal transmission. Designed for both indoor and outdoor installations, it supports frequencies up to 3 GHz with VSWR 1.3. Easy to install with secure hex crimp, its RoHS compliant, moisture and oxidation resistant, and suitable for cable TV, satellite, CCTV, and broadband applications. Available with customizable length and bulk packaging options from leading exporters, manufacturers, and suppliers in India.

Applications & Features of F Connector Female 75 Ohm Straight Crimp

The F Connector Female 75 Ohm Straight Crimp excels in RF signal transmission, making it ideal for cable TV, satellite TV, CCTV, and broadband Internet connections. Key features include unparalleled corrosion resistance, easy hex crimp installation, and a secure threaded locking mechanism. Its nickel-plated brass body resists moisture and oxidation, providing longevity in harsh conditions. Primary competitive advantages include high signal fidelity, robust material quality, and compliance with RoHS standardsmaking it the finest choice for both professional and domestic media systems.

Sample Policy, Packaging, and Main Domestic Market

Samples of the F Connector Female 75 Ohm Straight Crimp are available at a nominal charge. Packaging is tailored for bulk orders or customized as per client requirements, ensuring secure shipping through reliable logistics partners. Each shipment is carefully packed to maintain product integrity from the manufacturer to the client. The main domestic market for this connector spans across India, meeting the needs of wholesalers, suppliers, and end-users with prompt logistics solutions and consistent product quality.

FAQs of F Connector Female 75 Ohm Straight Crimp:

Q: How do I install the F Connector Female 75 Ohm Straight Crimp?

A: Installation is straightforward use a hex crimp tool to securely attach the connector to a compatible coaxial cable. Ensure the threaded coupling is properly tightened for a stable connection.

Q: What are the main applications of this F Connector?

A: This connector is primarily used for cable television, satellite TV, CCTV surveillance, and broadband internet signal transmission, offering reliable RF connectivity for domestic and commercial environments.

Q: When should I consider replacing my existing connectors with this model?

A: Replace existing connectors if you experience signal loss, corrosion, or frequent disconnections. This models corrosion resistance and robust design provide a longer-lasting and more secure connection.

Q: Where can I use this connector indoor or outdoor settings?

A: The connectors nickel-plated brass body and moisture resistance make it suitable for both indoor and outdoor installations, ensuring dependable performance in various environments.

Q: What benefits does the gold-plated center pin provide?

A: The gold-plated center pin enhances conductivity and signal transmission, reducing losses and improving overall RF performance in your cabling infrastructure.

Q: How is the connector packaged and shipped?

A: Packaging is available in bulk or customized as per order, ensuring secure shipping. Products are packaged to protect against damage during transit, supported by efficient logistics providers in India.
