FAKRA SMB Connector C Type Brown Coax Male Through Hole

FAKRA SMB Connector C Type Brown Coax Male Through Hole Specification

Core Number
1

Diameter
Standard FAKRA C Type

Number of Conductor
1

Cable Type
N/A (PCB Through Hole type)

Impedance
50 Ohm

Usage & Applications
Automotive, communication, Antenna, GPS, Telematics

Operating Temperature
-40C to +105C

Conductor Type
Single-core center pin

Install Type
Through Hole PCB Mount

Conductor Shape
Round Pin

Weight
Approx. 4g

Features
Color coded housing, easy snap-locking mechanism, high frequency stability, shock & vibration resistant, reliable signal transmission

Core Material
Brass

Locking Type
Snap-in, secure locking

Insulation
PEI, PBT

Rated Temperature
-40C to +105C

Dielectiric Strength
1000V RMS min

Product Type
FAKRA SMB Connector C Type Male

Length
Standard PCB mount; customized upon request

Voltage
Max 335 V RMS

Insulation Material
PEI (Polyetherimide), PBT (Polybutylene Terephthalate)

Application
Automotive RF communication, GPS, Antenna, Infotainment systems, Telematics

Conductor Material
Brass/Gold or Tin-plated

Jacket Material
N/A (Connector only)

Storage Temperature
-55C to +125C

Connector Color
Brown

Shield Material
Copper Alloy/Nickel-plated

Jacket Color
N/A (Connector only)

Dimension (L*W*H)
Standard FAKRA C Type/Special dimensions on request

Color
Brown (housing)

Material
Housing: PBT, Contacts: Brass

Size
Standard FAKRA C Type

Insulation Resistance
>1000 M

RoHS Compliant
Yes

Packaging
Tray or Tape & Reel (customized)

Mounting Type
PCB Through Hole

Connector Gender
Male

Center Contact Plating
Gold plated

Contact Resistance
Center: 10 m, Outer: 5 m

Outer Contact Plating
Tin/Nickel plated

Coding
C Type

VSWR
1.3 max (up to 3 GHz)

Termination Style
Through Hole Soldering

Frequency Range
DC to 3 GHz

Standards
DIN 72594-1, ISO 20860-1/2

Mating Cycles
25 cycles

FAKRA SMB Connector C Type Brown Coax Male Through Hole Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About FAKRA SMB Connector C Type Brown Coax Male Through Hole

Main Specifications
Frequency Range	DC-6GHz
Insulation Resistance	500M
Voltage Rating	60V AC(rms)
Current Rating	0.5A AC
Withstanding Voltage	200V AC
Working Temperature	-40C to +90C

Superior Signal Integrity and Durability

This connector boasts a frequency range of DC to 3 GHz and maintains a VSWR of 1.3, ensuring minimal signal loss and reliable transmission. Its shock and vibration resistance make it ideal for automotive and demanding communication environments. The contact resistance remains low, with gold-plated center contacts and tin/nickel-plated outer contacts for superior performance and longevity.

Simple and Secure Installation for Professional Applications

Engineered for easy integration, the FAKRA SMB Connector features a snap-in locking mechanism and is designed for through-hole PCB mounting. PEI and PBT insulation materials contribute to safe and robust installations, while the connector provides optimal fit and compatibility with standard FAKRA C Type dimensions. Various packaging options allow for streamlined manufacturing and assembly.

FAQs of FAKRA SMB Connector C Type Brown Coax Male Through Hole:

Q: How is the FAKRA SMB Connector C Type Brown Coax installed onto a PCB?

A: The connector uses a through-hole soldering method, enabling secure and stable insertion into PCB boards. Its snap-locking housing ensures a reliable physical and electrical connection during automotive and communication system assembly.

Q: What distinguishes this connectors performance in high-frequency automotive applications?

A: With a frequency range from DC to 3 GHz and VSWR of 1.3 max, the connector guarantees high frequency stability, minimal signal distortion, and consistent performance under shock and vibration, making it suitable for RF communication, GPS, and telematics.

Q: When should this connector be chosen for your project?

A: Select this connector when you require color-coded, snap-locking RF connectors for through-hole PCB mounting in automotive, GPS, antenna, or infotainment systems. Its robust design, offering up to 25 mating cycles and high insulation resistance, ensures longevity and reliability.

Q: Where is this connector commonly used and what applications does it serve?

A: It is widely applied in the automotive industry, specifically for RF communication modules, GPS units, antenna interfaces, infotainment systems, and telematics, providing dependable signal transmission within vehicles.

Q: What is the process for customizing the connectors packaging or dimensions?

A: Customized packaging (tray or tape & reel) and special dimensions can be requested from the manufacturer prior to ordering, catering to specific assembly line or installation requirements. Consult your supplier to specify needs during procurement.

Q: What benefits do the gold and tin/nickel plated contacts provide?

A: Gold plating on the center contacts enhances conductivity and prevents oxidation, while tin/nickel plating on the outer contacts offers extra corrosion resistance and mechanical durability, ensuring consistent electrical performance over time.
