IPEX Connector Solder Surface Mount

IPEX Connector Solder Surface Mount Specification

Operating Temperature
-40C to +85C

Features
High-density design, robust soldering, compact form factor, suited for high frequency signal transmission

Impedance
50 Ohm (typical for RF signal)

Insulation
LCP high temperature resistant

Core Number
Single (per connection)

Rated Temperature
-40C to +85C

Diameter
3.0 mm (outer)

Core Material
Copper Alloy

Tensile Strength
NA (typically not specified for connectors)

Usage & Applications
PCB RF interconnect, Wi-Fi, GPS, Bluetooth, IoT device assembly

Install Type
Surface Mount (SMD/SOP mounting method)

Cable Type
Not applicable (connector only)

Number of Conductor
1 (per contact); multi-pin available

Conductor Shape
Flat (PCB contact type)

Dielectiric Strength
500V AC for 1 minute

Conductor Type
Solid

Weight
Approx. 0.1g per connector

Locking Type
Snap Fit

Product Type
Board to Board RF Coaxial Connector (IPEX Surface Mount)

Length
Customizable, usually up to 50 mm (as per requirement)

Voltage
30V AC (maximum)

Insulation Material
LCP (Liquid Crystal Polymer)

Application
RF modules, wireless communication, PCB to PCB connections

Conductor Material
Phosphor Bronze

Jacket Material
NA (for PCB mounting connector type)

Storage Temperature
-40C to +85C

Connector Color
Metallic Silver

Shield Material
Copper Alloy with Nickel Plating

Jacket Color
NA (bare connector)

Dimension (L*W*H)
3.0 x 3.0 x 1.0 mm (approx.)

Material
LCP insulator, Copper Alloy contacts

Color
Silver

Size
Micro size, 3.0 mm footprint

Compliance
RoHS Compliant

Insulation Resistance
500 M @ 100V

Package Type
Tape and Reel (for automated SMD assembly)

Flammability Rating
UL94V-0

Frequency Range
DC to 6 GHz

Mating Cycles
30 times

Connector Series
IPEX MHF Series

Contact Resistance
50 m

Vibration Resistance
Conforms to IEC 60068-2-6

Mounting Type
Surface Mount (Reflow Soldering Compatible)

IPEX Connector Solder Surface Mount Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About IPEX Connector Solder Surface Mount

Main Specifications
Frequency Range	DC-6GHz
Insulation Resistance	500M
Voltage Rating	60V AC(rms)
Current Rating	0.5A AC
Withstanding Voltage	1000V AC
Working Temperature	-30C to +70C

Superior RF Performance

Engineered for applications requiring reliable high-frequency signal transmission, this IPEX connector delivers consistent performance from DC up to 6 GHz. Its solid, flat phosphor bronze contacts, paired with a 50 Ohm impedance, ensure minimal signal loss and high integrity in demanding environments such as wireless communication and IoT devices.

Efficient Surface Mount Design

Optimized for automated SMD assembly, the surface mount package (tape and reel) simplifies integration into PCBs. Its compact dimensions and robust snap-fit locking mechanism guarantee secure placement and connectivity, while RoHS compliance aligns with modern environmental and safety standards.

Reliable Construction and Compliance

Manufactured using high-temperature resistant LCP insulation and copper alloy contacts with nickel plating, the connector withstands rigorous conditions, including vibration (IEC 60068-2-6) and a wide operating temperature range (-40C to +85C), ensuring longevity and stability in diverse electronic assemblies.

FAQs of IPEX Connector Solder Surface Mount:

Q: How is the IPEX Connector installed on a PCB?

A: The connector is designed for surface mount installation using reflow soldering. It is supplied in tape-and-reel packaging, compatible with automated SMD assembly processes, ensuring efficient and reliable placement on PCB boards.

Q: What types of applications is this IPEX Connector suitable for?

A: Ideal applications include RF modules, wireless communication devices (such as Wi-Fi, GPS, Bluetooth), IoT device assembly, and PCB-to-PCB connections requiring high-frequency transmission and a micro footprint.

Q: What are the key benefits of using a high-density IPEX MHF Series connector?

A: Key benefits encompass space-saving design due to its compact form factor, reliable snap-fit locking, excellent signal transmission performance up to 6 GHz, and robust structural integrity under vibration and thermal stress.

Q: When should I consider customizing the connectors length?

A: Custom connector lengths, typically up to 50 mm, are recommended when specific board layouts or device designs require precise interconnect spacing. Contact the manufacturer or supplier to specify your exact requirements.

Q: What materials are used in the construction of this connector, and how do they enhance durability?

A: It utilizes LCP (Liquid Crystal Polymer) for insulation, copper alloy with nickel plating for shielding, and phosphor bronze for solid conductors. These materials offer high-temperature resistance, excellent electrical properties, and superior mechanical robustness even in harsh environments.

Q: Where is this connector manufactured and supplied from?

A: This IPEX connector is manufactured, exported, and supplied from India, catering to global markets including exporters, wholesalers, and electronics manufacturers seeking reliable RF interconnect solutions.

Q: What compliance and safety standards does the connector meet?

A: It is RoHS compliant for environmental safety, meets IEC 60068-2-6 for vibration resistance, and has a UL94V-0 flammability rating, ensuring safety and regulatory adherence for various electronic applications.
