TNC Male Connector To SMA Male Straight Coaxial Cable With RG223 RG58

TNC Male Connector To SMA Male Straight Coaxial Cable With RG223 RG58 Specification

Product Type
TNC Male Connector To SMA Male Straight Coaxial Cable

Number of Conductor
1

Conductor Diameter
0.9 mm (approx., for inner conductor)

Conductor Number
Single central conductor

Armored Material
No (not armored)

Jelly Filled
No

Rip Cord
No

Insulation
PE (Polyethylene), Foam or Solid (typically)

Installation Guideline
Suitable for RF communication setups, antennas, test equipment, indoor and outdoor, follow standard coaxial installation practices.

Jacket
PVC (Polyvinyl Chloride) or similar

Pairs
Not applicable (single core coaxial)

Color
Black (cable jacket)

No Of Core
1

No Of Pairs
0

Heat Proof
Yes (withstands moderate heat; commonly up to 70°C for RG223/RG58)

Frequency Range
Up to 3 GHz (depends on cable type and length)

Shielding
Double shielded (RG223), Single shield (RG58)

Length
Custom as per requirement (standard options available)

Operating Temperature
-40°C to +70°C

Impedance
50 Ohms

Application
RF transmission, WiFi antennas, GPS, communication devices, test equipment

Connector A
TNC Male

Voltage Rating
Up to 750V (depending on cable)

Cable Type
RG223 / RG58 Coaxial Cable

Connector B
SMA Male

Durability
UV and corrosion resistant jacket

Orientation
Straight

TNC Male Connector To SMA Male Straight Coaxial Cable With RG223 RG58 Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

TNC Male Connector To SMA Male Straight Coaxial Cable With RG223 RG58 About

Description:RF Coaxial Cable,TNC Straight Male,SMA StraightMale,RG223 RG58 Cable Assembly

RF Coaxial Cable,TNC Straight Male,SMA Straight Male,RG223 RG58 Cable Assembly
Used for Wireless communication and Wireless LAN;
Application include Mobile Phone, PC, GPS, Network Storage Equipment, Medical, Lighting, Remote Control, etc;
Pre-assemblied with different RF connectors for choice. Size and cable length can be customized;
From the OEM Original Factory, same quality with much better price.

High-Performance RF Cable Assembly

Engineered for precise signal transfer, this cable assembly combines a TNC Male connector with an SMA Male connector, delivering stable RF performance up to 3 GHz. The use of RG223 or RG58 coaxial cable allows selection between double or single shielded variants, balancing durability and flexibility as required by your application. Widely suited for testing, antennas, and communication equipment, this connector-cable combination supports demanding environments and is easy to install following standard practices.

Durability for Indoor and Outdoor Use

The cable features a rugged PVC jacket, offering robust resistance to UV rays and corrosion, making it ideal for both outdoor installations and harsh industrial environments. With an operating temperature range between -40C to +70C, and voltage rating up to 750V (depending on cable type), the assembly maintains reliable performance under varying conditions, providing long-term dependability for your setup.

FAQs of TNC Male Connector To SMA Male Straight Coaxial Cable With RG223 RG58:

Q: How do I select between RG223 and RG58 for my coaxial cable assembly?

A: RG223 provides double shielding, making it suitable for environments where enhanced shielding and durability are needed, while RG58 is lighter and single shielded. Your choice should be based on shielding requirements, installation environment, and performance needs.

Q: What is the recommended installation process for the TNC Male to SMA Male coaxial cable?

A: Install the cable by following standard coaxial practices: avoid sharp bends, ensure connectors are securely fastened, and protect the cable from physical damage. The PVC jacket and insulation allow for both indoor and outdoor setups, but consider environmental factors and mounting needs.

Q: When should I use this cable assembly in RF systems?

A: This assembly is ideal when you require a secure connection between TNC Male and SMA Male interfaces, especially in RF transmission, WiFi antennas, GPS modules, test equipment, or communication devices operating up to 3 GHz.

Q: Where can this cable assembly be utilized for best performance?

A: It is suited for a variety of environmentslaboratories, telecom facilities, outdoor antenna installations, and industrial settings. The cables resistance to UV and corrosion ensures longevity outdoors, while its compact profile fits well indoors.

Q: What benefits does the double shielded RG223 variant offer over RG58?

A: RG223 provides superior shielding and noise protection, crucial for locations with high electromagnetic interference or applications demanding minimal signal loss.

Q: How does the cable ensure durability in different conditions?

A: The assembly features a UV and corrosion-resistant PVC jacket, PE insulation, and robust connector interfaces, supporting reliable function from -40C to +70C and moderate heat exposure. This makes the cable suitable for most climate conditions in India and globally.

Q: Is the cable offered in custom lengths, and how can I request a specific size?

A: Yes, custom lengths are available to match installation requirements. Standard options are offered, but you can request a specific length from the exporter or manufacturer during the ordering process.
