TNC Male To N Female Cable 4 Hole Flange RG174 Cable Coax Assembly

TNC Male To N Female Cable 4 Hole Flange RG174 Cable Coax Assembly Specification

Product Type
Coaxial Cable Assembly

Number of Conductor
1

Conductor Diameter
Approximately 0.47 mm

Conductor Number
Single

Jelly Filled
No

Rip Cord
No

Insulation
Foam Polyethylene

Installation Guideline
Designed for RF signal transmission, ensure proper connection torque for both TNC and N connectors.

Jacket
PVC

Color
Black

No Of Core
1

Heat Proof
Standard Heat Resistance

Connector 2
N Female 4-Hole Flange

Mounting Type
Panel Mount (N Female 4-Hole Flange)

Frequency Range
DC to 6 GHz

Connector Plating
Nickel Plated

Cable Type
RG174

Impedance
50 Ohm

Voltage Rating
Maximum 300V

Connector 1
TNC Male

Shielding
Tinned Copper Braiding

Operating Temperature
-40°C to +85°C

Cable Length
Custom Lengths Available

Application
RF Signal Transmission, Telecom, Wireless Infrastructure

TNC Male To N Female Cable 4 Hole Flange RG174 Cable Coax Assembly Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

TNC Male To N Female Cable 4 Hole Flange RG174 Cable Coax Assembly About

Description:RF Coaxial Cable,TNC,Straight, Male,NType,Straight, Female,RG174 Cable

RF Coaxial Cable,TNC,Straight, Male,N Type,Straight, Female,RG174 Cable
Used for Wireless communication and Wireless LAN;
Application include Mobile Phone, PC, GPS, Network Storage Equipment, Medical, Lighting, Remote Control, etc;
Pre-assemblied with different RF connectors for choice. Size and cable length can be customized;
From the OEM Original Factory, same quality with much better price.

Superior Connectivity for RF Transmission

Experience reliable and consistent signal transmission with our RG174 coax assembly, specifically engineered for RF and telecom networks. The combination of TNC male and N female flange connectors provides flexibility and secure panel mounting for a variety of wireless infrastructure setups.

Flexible Customization for Your Needs

Choose the perfect cable length to match your requirements. Whether for large-scale installations or targeted signal routing, our custom-length options accommodate diverse projects and environments. Each assembly is manufactured for dependable operation in challenging temperatures, from -40C to +85C.

Built For Durability and Performance

The RG174 cable incorporates a single conductor insulated by foam polyethylene, shielded in tinned copper braiding, and jacketed in black PVC for resilience. Nickel-plated connectors resist corrosion and wear, sustaining signal integrity over time. Designed for panel mount applications, the N female 4-hole flange ensures a secure and stable connection.

FAQs of TNC Male To N Female Cable 4 Hole Flange RG174 Cable Coax Assembly:

Q: How should I properly install the TNC Male to N Female 4-Hole Flange RG174 cable assembly?

A: To install, mount the N female connector using the 4-hole flange to the designated panel, ensuring secure fixation. Torque both the TNC male and N female connectors per manufacturer recommendations for optimal signal transmission and reliability.

Q: What makes this coax cable assembly suitable for wireless infrastructure and telecom applications?

A: Its 50 Ohm impedance, wide frequency support from DC to 6 GHz, and robust shielding enable efficient RF signal transmission. The assembly is engineered for stability and minimal signal loss in critical telecom and wireless installations.

Q: When is customization of cable length recommended for this assembly?

A: Custom cable lengths are ideal when standard sizes dont meet spatial constraints or specific project requirements. You can request tailored lengths to ensure precise connectivity without excess cable clutter.

Q: Where can this assembly be panel mounted?

A: The N female connectors 4-hole flange is designed for panel mounting on chassis, control cabinets, or infrastructure panels in telecom, RF, or wireless systems, providing secure and stable integration.

Q: What is the process for exporting or sourcing this cable assembly in India?

A: As an exporter, manufacturer, supplier, and wholesaler, we offer streamlined sourcing directly from India. Contact us for bulk orders, custom manufacturing, or international exports and our team will guide you through the process.

Q: How does the shielding enhance cable performance?

A: The tinned copper braiding provides superior EMI protection, reducing interference and preserving signal quality, which is essential for high-frequency RF transmissions.

Q: What benefit does the nickel plating on the connectors offer?

A: Nickel plating delivers increased corrosion resistance and longer connector lifespan, resulting in sustained conductivity and reliable performance even in harsh environments.
