TNC To SMA Cable Assembly RG178 Pigtail 15CM

TNC To SMA Cable Assembly RG178 Pigtail 15CM Specification

Product Type
TNC to SMA Cable Assembly

Number of Conductor
1

Conductor Diameter
~0.3 mm

Conductor Number
1

Jelly Filled
No

Rip Cord
No

Insulation
PTFE

Installation Guideline
Suitable for RF and microwave signal transmission, install with compatible TNC and SMA connectors

Jacket
FEP (Fluorinated Ethylene Propylene)

Pairs
0

Color
Brown (cable), Silver (connector)

No Of Core
1

No Of Pairs
0

Heat Proof
Yes

Application
RF, GPS, WiFi, WLAN, Antenna, Instrumentation

Impedance
50 Ohms

Connectors
TNC Male to SMA Male

Voltage Rating
Up to 1000V RMS

Cable Type
RG178

Frequency Range
DC to 3 GHz

RoHS Compliant
Yes

Cable Length
15 cm

Operating Temperature
-55°C to +200°C

Shielding
Silver-plated copper braid

TNC To SMA Cable Assembly RG178 Pigtail 15CM Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About TNC To SMA Cable Assembly RG178 Pigtail 15CM

Description:RF Coaxial Cable,RP TNC Straight Male,SMAStraight Female,RG178 Cable Assembly

RF Coaxial Cable,RP TNC Straight Male,SMA Straight Female,RG178 Cable Assembly
Used for Wireless communication and Wireless LAN;
Application include Mobile Phone, PC, GPS, Network Storage Equipment, Medical, Lighting, Remote Control, etc;
Pre-assemblied with different RF connectors for choice. Size and cable length can be customized;
High Quality with 30 days 100% Money back;
From the OEM Original Factory, same quality with much better price.

Exceptional Performance for RF Applications

This cable assembly stands out for its stable signal transmission and low loss within the frequency range of DC to 3 GHz. The RG178 coaxial design, combined with silver-plated copper braided shielding, minimizes interference and optimizes performance for RF, antenna, GPS, and WiFi setups. Its robust PTFE insulation and FEP jacket guarantee resilience in harsh conditions.

Reliable Build Quality and Environmental Resistance

Engineered to perform reliably across a wide temperature spectrum from -55C to +200C, this cable is heatproof and suited for both indoor and outdoor installations. The quality materials and precision connectors ensure compatibility with standard TNC and SMA interfaces. RoHS compliance makes it environmentally friendly for global distribution.

FAQs of TNC To SMA Cable Assembly RG178 Pigtail 15CM:

Q: How should I install the TNC to SMA Cable Assembly RG178 Pigtail for optimal performance?

A: For optimal performance, connect the TNC male and SMA male connectors to compatible RF equipment and antenna interfaces. Ensure a secure fit to minimize signal loss and follow the recommended installation guideline for RF and microwave signal transmission.

Q: What makes this cable suitable for RF, GPS, WiFi, and instrumentation applications?

A: The cables low-loss RG178 design, 50 Ohm impedance, and frequency range up to 3 GHz deliver reliable signal transmission required by RF, GPS, WiFi, WLAN, antenna, and instrumentation systems.

Q: Where can the TNC to SMA Cable Assembly be effectively used?

A: This assembly is ideal for usage in laboratories, telecom installations, radar equipment, wireless networks, and any setting requiring precise RF connectivity between devices featuring TNC and SMA interfaces.

Q: What benefits does silver-plated copper braid shielding provide?

A: Silver-plated copper braid shielding enhances signal integrity by minimizing external electromagnetic interference, ensuring robust performance in demanding RF environments.

Q: When is it necessary to use a cable with high operating temperature tolerance like this assembly?

A: Use this assembly in applications exposed to extreme temperatures, such as outdoor installations or test environments, as it withstands from -55C to +200C without signal degradation.

Q: Is the RG178 cable assembly compliant with environmental standards?

A: Yes, the assembly is RoHS compliant, which assures it meets global restriction standards for hazardous substances, making it safe for various applications.

Q: What process should be followed for maintaining this cable assembly?

A: Regularly inspect connectors for secure attachment and check cable integrity, especially after exposure to harsh conditions or frequent repositioning. Avoid excessive bending to preserve the conductor and insulation.
