7/16 Male DIN Connector Angled Crimp Type For Cable

7/16 Male DIN Connector Angled Crimp Type For Cable Specification

Diameter
Compatible with 1/2 cable, outer diameter approx. 21 mm

Core Number
1

Features
High durability, low VSWR, stable performance, weatherproof, corrosion-resistant

Dielectiric Strength
4 kV rms (sea level)

Impedance
50 Ohms

Tensile Strength
450 N (cable retention)

Rated Temperature
-40C to +85C

Usage & Applications
Cellular towers, outdoor RF equipment, high power transmission

Number of Conductor
One (signal pin)

Core Material
Brass-gold plated

Conductor Shape
Round pin

Locking Type
Threaded coupling (screw locking)

Weight
Approx. 110g

Insulation
PTFE

Conductor Type
Solid pin

Cable Type
Flexible/semirigid RF cables 1/2 or similar

Operating Temperature
-40C to +85C

Install Type
Crimp type, right-angle

Product Type
RF DIN 7/16 Male Crimp Type Angled Connector

Length
Standard/customized as required

Voltage
Up to 2700V (rms) max.

Insulation Material
PTFE

Application
RF and telecommunication cables, base stations, antenna installations

Conductor Material
Brass-gold plated

Jacket Material
Not applicable (connector only)

Storage Temperature
-55C to +125C

Connector Color
Silver

Shield Material
Brass/Nickel plated

Jacket Color
Not applicable (connector only)

Dimension (L*W*H)
Approx. 48 x 27 x 27 mm

Material
Body: Brass (nickel plated), Pin: Brass (gold plated), Insulator: PTFE

Color
Silver

Size
DIN 7/16; Angled (90 Degree)

Flame Retardancy
UL94 V-0 (insulator)

Insulation Resistance
>10000 M

Standard
DIN EN 60169-4

Frequency Range
Up to 7.5 GHz

RoHS Compliance
Yes

Surface Finish
Nickel Plated

VSWR
1.08 + 0.03 f (GHz)

Cable Entry
Crimp type, easy assembly

Waterproof Level
IP67 (mated)

Contact Resistance
Center conductor 0.4 m, Outer conductor 1.0 m

Connector Gender
Male (plug)

Mating Cycles
500 cycles

Angle Type
90 Right Angle

7/16 Male DIN Connector Angled Crimp Type For Cable Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About 7/16 Male DIN Connector Angled Crimp Type For Cable

Capitalise on the superlative performance of the 7/16 Male DIN Connector Angled Crimp Type for cable applications up to 7.5 GHz. Highlighted by its robust IP67 waterproofing, low contact resistance, and resplendent nickel-plated finish, this right-angle plug ensures excellent signal transmission even under demanding conditions. Backed by over 500 mating cycles and RoHS compliance, its crimp type design guarantees easy assembly and reliable cable retention. Pick yours for RF and telecommunication installations requiring stable, high-durability connections and corrosion-resistant properties. A smart choice for industrial professionals worldwide.

Competitive Advantages and Features of the Machine

The 7/16 Male DIN Connector Angled Crimp Type boasts excellent durability, flame retardancy (UL94 V-0), and a resplendent right-angle 90 design, ideal for compact spaces. With low VSWR and high insulation resistance, it delivers stable performance for RF installations. The easy crimp assembly streamlines installation, while a robust brass-gold plated pin ensures superlative conductivity. Simply insert, crimp, and secure using the screw locking for a secure fitperfect for outdoor and high-power transmission scenarios.

Export Markets, Delivery Estimates, and Sample Policy

Our offering is tailored for global markets, with major exports to Europe, Asia, North America, and Australia. Proposal amounts are customized per order, with logistics expertly managed to ensure efficient and safe delivery. Estimated delivery times vary by destination, generally ranging from 2 to 4 weeks. We support sampling to qualified buyerssample policies and costs are discussed within your project estimate for transparency and convenience.

FAQs of 7/16 Male DIN Connector Angled Crimp Type For Cable:

Q: How do I install the 7/16 Male DIN Connector Angled Crimp Type?

A: Installation involves stripping the cable, inserting it into the connector, crimping the entry point securely, and tightening the threaded coupling for a stable, weatherproof connection.

Q: What types of cables is this connector compatible with?

A: It is designed for flexible and semirigid RF cables with an outer diameter of approximately 21 mm (e.g., 1/2 cables), making it versatile in telecommunication setups.

Q: Where can the 7/16 Male DIN Connector be used?

A: This connector is ideal for cellular towers, outdoor RF equipment, antenna installations, and other high-power transmission and communication applications.

Q: What are the main advantages of this connectors design?

A: The connector features a right-angle form for tight spaces, low VSWR for efficient signal transfer, corrosion-resistant brass/nickel materials, and flame-retardant PTFE insulation.

Q: What sample and delivery process is offered?

A: Samples are offered to qualified buyers based on your proposal amount, and logistics ensure prompt shipments with delivery estimates typically ranging from 2 to 4 weeks.
