Fakra Connector Types Z Female Crimp Solder

Fakra Connector Types Z Female Crimp Solder Specification

Operating Temperature
-40°C to +105°C

Core Material
Copper

Impedance
50 Ohm

Conductor Shape
Round

Diameter
8.2 mm max

Cable Type
RF coaxial cable (optional with cable)

Tensile Strength
Minimum 90 N with crimp sleeve

Armored Material
Not armored

Rated Temperature
-40°C to +105°C

Features
Z type code for automotive RF communication; Secure locking system; Snap-on interface; Crimp and solder termination compatibility; Suitable for high frequency up to 6 GHz

Weight
Approx. 7g

Conductor Type
Stranded or solid (as per cable)

Number of Conductor
1

Usage & Applications
Automotive, infotainment, GPS navigation, telecommunications

Locking Type
Snap-on with locking interface

Insulation
PTFE dielectric

Install Type
Cable crimp/solder installation

Core Number
Single core

Dielectiric Strength
1000 V RMS min

Product Type
Fakra Connector Type Z Female Crimp Solder

Length
Standard as per cable or application need

Voltage
60 V RMS max

Insulation Material
PTFE

Application
GPS, GSM, automotive RF applications, multimedia interfaces, telematics

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-40°C to +85°C

Connector Color
Black

Shield Material
Copper alloy with tin plating

Jacket Color
Custom (default: black)

Dimension (L*W*H)
Refer to datasheet; typically approx 23 mm length

Material
Brass, PTFE, copper alloys

Color
Black or as specified

Size
Standard Fakra Z interface size

Contact Plating
Gold plated

Frequency Range
DC to 6 GHz

Return Loss
>20 dB up to 1 GHz

Humidity
95% max (non-condensing)

Mounting
Cable mount (crimp/solder)

RoHS Compliance
Yes

Connector Gender
Female

Vibration Endurance
Meets automotive requirements

Fakra Connector Types Z Female Crimp Solder Trade Information

Minimum Order Quantity
10 Pieces

Main Domestic Market
All India

Fakra Connector Types Z Female Crimp Solder About

Hot deal alert! The Fakra Connector Types Z Female Crimp Solder is designed for brilliance in automotive RF communication, featuring superb gold plating for optimal conductivity and a noble snap-on secure locking system. Highly compatible, it supports both crimp and solder terminations, offers outstanding frequency range (DC to 6 GHz), and maintains above-20 dB return loss up to 1 GHz. Scarce in supply, its crafted with copper alloy, PTFE insulation, and RoHS compliance, ensuring reliability in demanding conditions. Personalise jacket color to fit your needsideal for GPS, GSM, multimedia, and telematics.

Features & Application Areas of Fakra Connector Types Z Female Crimp Solder

Equipped with a Z type coding for secure automotive RF communication, the Fakra Connector Z Female offers a superb snap-on locking interface and robust cable crimp/solder compatibility. Its gold-plated contact ensures brilliant signal reliability across high-frequency applications up to 6 GHz. This premium connector finds noble usage in GPS navigation systems, GSM modules, infotainment interfaces, and multimedia telematics for vehicles, supporting high performance in challenging automotive environments.

Payment Terms, Sample Availability & Export Market Arrival

Premium payment terms are available for bulk orders and trusted clients. Samples of the Fakra Connector Z Female can be provided upon request for product evaluation. With swift arrival in the main domestic and export markets, this connector is exclusively distributed to manufacturers, suppliers, and wholesalers across India and abroad. We cater to high-volume export requirements, ensuring secure transaction processes, timely shipments, and optimal product support for all automotive applications.

FAQs of Fakra Connector Types Z Female Crimp Solder:

Q: How is the Fakra Connector Types Z Female installed in cables?

A: The connector can be attached using either crimp or solder termination methods, allowing compatibility with a variety of RF coaxial cables and on-site installation convenience.

Q: What are the key benefits of using Z type coding in automotive connectors?

A: Z type coding ensures secure and accurate mating within automotive RF communication systems, minimizing interference and ensuring specific network compatibility for vital connections.

Q: Where can the Fakra Connector Types Z Female be applied?

A: This connector is ideal for use in automotive GPS, GSM modules, infotainment systems, telematics, and multimedia interfaces requiring high-frequency RF connections.

Q: When are samples of the Fakra Connector Types Z Female available for testing?

A: Samples can be requested prior to order placement, allowing clients to evaluate product compatibility and performance within their application environments.

Q: What process should be followed to personalize the jacket color of the connector?

A: Jacket color personalization can be specified during the order process, enabling adaptation to specific project or branding requirements, with the default color provided as black.

Q: How does the secure locking system benefit high-vibration automotive environments?

A: The snap-on locking interface delivers superior vibration endurance, meeting automotive standards and ensuring the connector stays firmly in place during vehicle operation.
