N Connector Female Bulkhead

N Connector Female Bulkhead Specification

Diameter
Approx. 18 mm

Install Type
Bulkhead

Conductor Type
Solid

Insulation
PTFE

Features
High corrosion resistance, Robust construction, Reliable signal transmission

Tensile Strength
High mechanical strength

Rated Temperature
-55C to +155C

Cable Type
RF Coaxial

Impedance
50 Ohm

Core Number
Single Core

Usage & Applications
RF transmission, Wireless base stations, Coaxial cable connections

Number of Conductor
1

Operating Temperature
-55C to +155C

Conductor Shape
Round pin

Locking Type
Threaded coupling

Dielectiric Strength
1000 V RMS min

Core Material
Brass

Weight
Approx. 22 grams

Product Type
N Connector Female Bulkhead

Length
Custom as per requirement

Voltage
Up to 500 V

Insulation Material
PTFE (Polytetrafluoroethylene)

Application
RF communication, Antenna connections, Wireless systems

Conductor Material
Brass, Gold plated

Jacket Material
Nickel-plated brass

Storage Temperature
-40C to +85C

Connector Color
Silver

Shield Material
Brass, Nickel plated

Jacket Color
Silver

Dimension (L*W*H)
As per standard N connector dimensions (approx. 31x18x18 mm)

Color
Silver

Material
Brass, PTFE, Nickel plating

Size
Standard N-type (approx. 18 mm hex nut diameter)

Mounting Style
Panel Mount (Bulkhead)

Attachment Method
Rear bulkhead nut and washer

RoHS Compliance
Yes

VSWR
1.3 (up to 3 GHz)

Ingress Protection
IP 67 (with appropriate gasket)

Frequency Range
DC to 11 GHz

Inner Contact Plating
Gold plated (minimum 2m)

Contact Resistance Center
< 1.5 m

Coupling Mechanism
Threaded

Contact Resistance Outer
< 1.0 m

N Connector Female Bulkhead Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About N Connector Female Bulkhead

Description: Panel Mount, jack/female,Straight/180,50,RG142,RG400,RG223, Bulkhead, Cable Connector

Accessories: nut+washer+o-ring

Features:

Panel Mount, jack/female, Straight/180,50,RG142,RG400,RG223, Bulkhead, Cable Connector;
Great performance with DC to 11GHz Frequency and 50 ohm impedance;
Threaded coupling mechanism ensure durability and stability for vibration application;
Medium size used in military, industry or consumption electronic area, etc;
From the OEM Original Factory, same quality with much better price.

Main Application of N Connectors:

Aerospace and Defense: Radar Equipment
Medical: Ablation equipment
Commercial Vehicle: Bluetooth and GPS
Telecommunications: Antennas, Base Stations, Passive/Active Base Station Components, Telecommunication hardware
Data/Communications: Broadcast Electronics, Wifi
Industrial: Machine to Machine Communications

Robust Construction for RF Applications

Designed for high durability, the N Connector Female Bulkhead uses nickel-plated brass with gold-plated contacts and PTFE insulation, ensuring excellent corrosion resistance. Its high mechanical strength and IP67 rating (with appropriate gasket) make it suitable for harsh environments found in wireless base stations and antenna installations.

Secure Panel Mounting and Easy Installation

This connector employs a threaded coupling and rear bulkhead nut and washer for secure attachment. Standard N-type dimensions allow compatibility with typical RF coaxial setups. The panel mount design enables straightforward integration in system enclosures and equipment housings for reliable operation.

Superior Electrical Performance and Reliability

With a frequency range from DC to 11 GHz, low contact resistance, and a VSWR 1.3 (up to 3 GHz), this connector guarantees stable and efficient signal transmission. Gold plating and PTFE insulation further enhance reliability, supporting voltages up to 500 V and temperatures from -55C to +155C.

FAQs of N Connector Female Bulkhead:

Q: How is the N Connector Female Bulkhead mounted onto equipment panels?

A: This connector utilizes a panel mount (bulkhead) design with a rear bulkhead nut and washer, allowing secure installation through a drilled hole in the panel. The threaded coupling mechanism ensures a firm and stable fit, preventing loosening during operation.

Q: What is the process for attaching RF coaxial cables to this connector?

A: RF coaxial cables are typically terminated with compatible N-type male connectors that mate with the female bulkhead connector via a threaded coupling. This ensures robust, low-resistance contact for reliable signal transmission in wireless and RF applications.

Q: Where can the N Connector Female Bulkhead be used?

A: It is suited for a range of RF transmission setups, including antenna connections, wireless base stations, and other telecommunications systems that require panel-mounted coaxial interfaces. Its IP67 ingress protection (when used with a suitable gasket) enables installation in indoor and outdoor environments.

Q: What benefits does gold-plated inner contact offer in this connector?

A: The minimum 2m gold plating on the inner contact greatly enhances corrosion resistance, reduces contact resistance, and improves long-term electrical reliability, especially in high-frequency and demanding RF applications.

Q: How does this connector ensure reliable signal transmission up to 11 GHz?

A: Robust engineering, low contact resistance, precision contacts, and quality materials such as brass, PTFE, and nickel plating result in stable performance with a VSWR 1.3 up to 3 GHz, supporting frequencies from DC to 11 GHz and voltages up to 500 V.

Q: What is the operating temperature range for this connector?

A: The N Connector Female Bulkhead is designed to operate reliably over a broad temperature range, from -55C to +155C, suitable for both extreme indoor and outdoor RF applications.
