Send InquiryN Type Cable Connectors Straight Male To SMA Male RP Cable With RG58
N Type Cable Connectors Straight Male To SMA Male RP Cable With RG58 Specification
- Product Type
- N Type Straight Male to SMA Male RP Cable with RG58
- Number of Conductor
- 1
- Conductor Diameter
- 0.81 mm (nominal, RG58 inner conductor)
- Conductor Number
- 1
- Armored Material
- None (standard RG58 is not armored)
- Jelly Filled
- No
- Rip Cord
- No
- Insulation
- Solid polyethylene (RG58 cable standard)
- Installation Guideline
- Suitable for indoor and outdoor RF applications, follow manufacturer specifications for bending radius and termination
- Jacket
- PVC (Polyvinyl Chloride), Black
- Color
- Black (Cable), Silver (Connectors)
- No Of Core
- 1
- Heat Proof
- Standard heat resistance (not designed for high temperature environments)
- VSWR
- 1.5:1 (typical for short lengths)
- Insertion Loss
- Approximately 0.39 dB/m at 1 GHz (varies with length)
- Shielding
- Braided copper, tinned
- Voltage Rating
- Up to 500V (RG58 standard)
- Frequency Range
- 0-3 GHz (Depend on Cable Length)
- Operating Temperature Range
- -40C to +85C
- RoHS Compliance
- Yes
- Applications
- RF Communication, Wireless Antennas, WiFi, Laboratory Equipment
- Impedance
- 50 ohms
- Cable Type
- RG58 Coaxial Cable
- Environmental Protection
- Standard indoor/outdoor use; not IP rated
- Cable Length
- Customizable, e.g., 1m, 3m, 5m, etc.
- Connector 1 Type
- N Type Straight Male
- Connector 2 Type
- SMA Male Reverse Polarity (RP)
N Type Cable Connectors Straight Male To SMA Male RP Cable With RG58 Trade Information
- Minimum Order Quantity
- 5 Pieces
- Main Domestic Market
- All India
About N Type Cable Connectors Straight Male To SMA Male RP Cable With RG58
Description:RF Coaxial Cable,N Type Straight Male,SMAStraight Male RP,RG223 RG58 Cable Assembly
- RF Coaxial Cable,N Type Straight Male,SMA Straight Male RP,RG223 RG58 Cable Assembly
- Used for Wireless communication and Wireless LAN;
- Application include Mobile Phone, PC, GPS, Network Storage Equipment, Medical, Lighting, Remote Control, etc;
- Pre-assemblied with different RF connectors for choice. Size and cable length can be customized;
- From the OEM Original Factory, same quality with much better price.
Versatile RF Connectivity
Designed for both indoor and outdoor environments, this cable assembly supports a wide range of RF applications. It connects devices requiring N Type and SMA Male RP interfaces, making it suitable for wireless antennas, laboratory setups, and general RF communication. The standard 50 ohm impedance helps optimize signal transfer for frequencies up to 3 GHz, depending on the length selected.
Customizable Cable Lengths
With various cable lengths available, including 1m, 3m, and 5m options, this product accommodates tailored installations. Select the optimal length to minimize insertion loss and achieve precise performance in your application. The RG58 cables flexible PVC jacket and standard heat resistance ensure reliable operation in environments ranging from -40C to +85C.
FAQs of N Type Cable Connectors Straight Male To SMA Male RP Cable With RG58:
Q: How is the N Type Straight Male to SMA Male RP cable used in RF communication setups?
A: This cable assembly is typically used to connect RF devices such as routers, wireless antennas, or laboratory test equipment, ensuring efficient signal transmission between components that require N Type and SMA Male RP connectors.Q: What are the benefits of choosing customizable cable lengths for this product?
A: Customizable lengths allow users to select the exact cable size needed for their installation, which helps reduce signal loss, improve VSWR performance, and neatly fit the cable within the given space.Q: When should I consider using this cable for my wireless antenna installation?
A: You should use this cable for indoor or outdoor wireless antenna setups that require 0-3 GHz frequency range, a 50 ohm impedance, and connection interfaces involving N Type and SMA Male RP connectors. It is especially effective where standard RF coaxial cabling is specified.Q: Where can these cable assemblies be installed safely?
A: These cables can be installed both indoors and outdoors in standard environments, as the PVC jacket provides robust protection. However, they are not IP rated and should not be used in areas exposed to excessive moisture or harsh weather.Q: What process should I follow for proper installation of this RG58 cable assembly?
A: Follow manufacturer guidelines, ensuring the cables bending radius is not exceeded and the connectors are securely terminated. Avoid tension or sharp bends in the cable to maintain signal integrity and longevity.Q: What applications are best suited for N Type to SMA Male RP cable assemblies?
A: Typical applications include RF communications, wireless antenna installations, WiFi infrastructure, and laboratory equipment where these connector types and cable specifications are required for compatibility and performance.Price 80 INR/ Piece
- Minimum Order Quantity
- 5 Pieces
- Main Domestic Market
- All India
