SMB Connector Jack Straight Crimp Type For Cable RG316

SMB Connector Jack Straight Crimp Type For Cable RG316 Specification

Locking Type
Snap-on

Conductor Shape
Round

Weight
Approx. 4g

Insulation
PTFE

Install Type
Crimp Type

Diameter
Approx. 7mm

Conductor Type
Single

Number of Conductor
1

Rated Temperature
-55°C to +155°C

Dielectiric Strength
1000V RMS min

Core Material
Copper

Usage & Applications
RF Circuits, Coaxial Cable Termination, Signal Transmission

Cable Type
RG316

Core Number
1

Impedance
50 Ohms

Operating Temperature
-55°C to +155°C

Tensile Strength
150N min (Cable retention)

Features
High frequency performance, Quick-connect/disconnect capability, Excellent vibration resistance, Precision machined contacts

Product Type
SMB Connector Jack Straight Crimp

Length
Standard (customizable as per cable length requirements)

Voltage
250V RMS max

Insulation Material
PTFE

Application
RF and Microwave applications, Telecommunication, Instrumentation

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-40°C to +80°C

Connector Color
Gold

Shield Material
Tinned Copper

Jacket Color
Customizable (Standard: Transparent/Black)

Dimension (L*W*H)
Approximately 18mm x 7mm x 7mm

Material
Brass (Body), Gold plated (Contact)

Color
Gold

Size
Standard SMB

Applicable Standards
IEC 61169-10

Finish
Gold plated

Interface Standards
MIL-C-39012

RoHS Compliance
Yes

VSWR
1.3:1 max @ 4 GHz

Connector Type
Jack (female pin)

Mating Cycles
>500

Contact Resistance
6 milliohms max

Cable Compatibility
RG316/U, RG174/U

Protection Level
IP50

Mounting Style
Cable mount

Frequency Range
DC to 4 GHz

Insertion Loss
< 0.1 dB @ 1 GHz

SMB Connector Jack Straight Crimp Type For Cable RG316 Trade Information

Minimum Order Quantity
5 Pieces

Main Domestic Market
All India

About SMB Connector Jack Straight Crimp Type For Cable RG316

Description: Cable Connector, Jack/female, Angled/90 ,50 , Crimp Type

Accessories: pin+ferrule

Features:

Cable Connector, Jack/female, Angled/90 , 50 , Crimp Type;
Snap-on coupling design for fast installation;
With boardband performance and low reflection;
To reduce your Cost by using die casting process in non-critical areas.
From the OEM Original Factory, same quality with much better price.

Main Application of SMB Connectors:

Aerospace and Defense: Test Stands
Medical: Telemetry
Commercial Vehicle: GPS
Telecommunications: Wireless Base Stations, Cellular Mobile System
Data/Communications: Routers, WIFI, Radio Boards
Industrial: M2M Communications, Process Controls, Video Systems,Instrumentation

High-Frequency Precision and Performance

This SMB Connector Jack delivers reliable signal integrity across frequencies from DC to 4 GHz, maintaining a voltage rating of 250V RMS and exhibiting minimal insertion loss. Its 50 Ohms impedance and gold-plated finishing enhance its suitability for demanding RF and microwave systems, enabling efficient performance in instrumentation and communication infrastructure.

Exceptional Durability and Robust Construction

Designed for resilience, the SMB Jack supports over 500 mating cycles and offers excellent cable retention (150N min). Precision-machined contacts and gold plating reduce wear while PTFE insulation tolerates extreme temperatures (-55C to +155C), ensuring longevity in challenging environments.

Easy Installation and Broad Compatibility

Featuring a straightforward crimp-type cable mount and snap-on locking, this connector guarantees quick, secure setups. Compatibility with RG316/U and RG174/U cables ensures versatile applications for signal transmission, RF circuits, and coaxial termination tasks.

FAQs of SMB Connector Jack Straight Crimp Type For Cable RG316:

Q: How is the SMB Connector Jack Straight Crimp Type installed onto RG316 cable?

A: This connector uses a crimp-type installation, suitable for RG316, RG174, and similar cables. Prepare the cable, insert it into the appropriate sections of the jack, and use a suitable crimping tool for secure and reliable termination. Once crimped, the connector delivers robust connectivity ideal for both field and factory installations.

Q: What are the key benefits of using this SMB Connector Jack for RF and microwave applications?

A: Primary advantages include high-frequency compatibility up to 4 GHz, excellent low insertion loss, precise impedance matching (50 Ohms), and outstanding vibration resistance. The gold-plated contacts and PTFE insulation offer superior signal integrity, durability, and temperature resilience, making it suitable for demanding RF environments.

Q: When should I choose this connector over other types for my telecommunication setup?

A: Select this connector when you require high-quality, quick-connect capability, and reliable performance for frequencies up to 4 GHz. Its compatibility with common coaxial cables like RG316 and RG174, along with its robust mechanical design, makes it especially suitable for telecommunications and signal processing setups requiring frequent mating cycles and secure signal retention.

Q: Where can this SMB Connector Jack be employed aside from RF circuits?

A: Beyond RF circuits, this connector is ideal for coaxial cable terminations in telecommunication equipment, microwave instrumentation, signal transmission lines, and laboratory instrumentation. Its reliable characteristics and customizable cable lengths add versatility across numerous electronic devices and systems.

Q: What is the process for customizing jacket color or cable length?

A: Customizations for cable length and jacket color can be requested during the ordering or quotation process. Standard options include transparent and black jackets, but other colors can be provided on demand to suit installation needs or organizational preferences.

Q: Is the SMB Connector Jack compliant with international standards?

A: Yes, the connector complies with MIL-C-39012 and IEC 61169-10 standards. This assures users of its quality, performance, and global interoperability for RF connectors.

Q: What protection and durability features does this jack offer during operation?

A: The connector provides IP50 protection against dust ingress, supports over 500 mating cycles, withstands tensile strengths of at least 150N, and tolerates a wide temperature range from -55C to +155C, ensuring reliable operation in rigorous environments.
