Send InquiryTNC Plug Male Straight 50 Rg58 Clamp For Cable
TNC Plug Male Straight 50 Rg58 Clamp For Cable Specification
- Dielectiric Strength
- 1500V RMS (between body and center conductor)
- Diameter
- Approx. 14mm (shell diameter)
- Insulation
- PTFE
- Weight
- Approx. 12g
- Tensile Strength
- Standard, suitable for frequent connect/disconnect
- Number of Conductor
- 1
- Impedance
- 50
- Usage & Applications
- Radio frequency signal transmission in wireless, networking, test equipment
- Locking Type
- Threaded coupling
- Core Material
- Copper
- Rated Temperature
- -40C to +85C
- Features
- Robust construction, reliable signal transmission, corrosion resistant metal body, secure locking mechanism
- Conductor Type
- Single core
- Install Type
- Clamp type for RG58 coaxial cable
- Operating Temperature
- -40C to +85C
- Conductor Shape
- Round
- Core Number
- Single
- Cable Type
- RG58 Coaxial
- Product Type
- TNC Plug Male Straight 50 RG58 Clamp Connector
- Length
- Customizable as per cable
- Voltage
- 500V RMS max
- Insulation Material
- PTFE (Polytetrafluoroethylene)
- Application
- RF and coaxial cable connections, telecommunications, wireless communications, antennas
- Conductor Material
- Copper
- Jacket Material
- PVC (Polyvinyl Chloride)
- Storage Temperature
- -40C to +85C
- Connector Color
- Silver
- Shield Material
- Tinned copper braid (for RG58 cable)
- Jacket Color
- Black
- Dimension (L*W*H)
- Approx. 34mm x 14mm x 14mm
- Color
- Silver
- Material
- Brass with nickel plating
- Size
- Supports RG58 cable (approx. 5mm outer cable diameter)
- Contact Plating
- Gold plated center contact
- Assembly Method
- Clamp & Solder
- Frequency Range
- DC to 11GHz
- Mating Cycles
- 500
- Flammability
- Jacket material rated to UL94 V-0 (If applicable)
- Waterproof Rating
- Non-waterproof
- Contact Resistance
- Center: 1.5 m; Outer: 1.0 m
- VSWR
- 1.3 (typical at 0~1 GHz)
- Insulation Resistance
- >= 5000 M
TNC Plug Male Straight 50 Rg58 Clamp For Cable Trade Information
- Minimum Order Quantity
- 5 Pieces
- Main Domestic Market
- All India
About TNC Plug Male Straight 50 Rg58 Clamp For Cable
Electrical Characteristics
- Impedance 50 ohm
- Frequency Range: 0~11 GHz for 50 ohm
- VSWR: Straight type 1.3max / R/A type 1.5max
- Dielectric Withstanding Voltage: 1500 V rms
- Working Voltage: 500 V rms
- Center Contact Resistance 3. m (Milliohms max.)
- Outer Contact Resistance 2.0 m (Milliohms max.)
- Insultation Resistance 5 10 m (Milliohms min.)
Mechanical Characteristics
- Coupling: 7/16-28 thread
- Contact Retention: 6 lbs min.
- Mating Durability: 500 cycles
Environmental Characteristics
- Environmental Characteristics: -65oC~+145oC
- Coupling Nut Retention: 100 lbs. min.
- Vibration: MIL-STD-202 Meth. 204
- Corrosion Resistance: MIL-STD-202 Meth. 101
Dependable RF Connectivity
Engineered for seamless radio frequency signal transmission, the TNC Plug Male Straight 50 RG58 Clamp features a secure threaded coupling and precise impedance matching. Its construction minimizes signal interference, ensuring stable and efficient performance in networking, test equipment, and antenna systems. Rely on its durable materials for dependable connections every time.
Simple and Secure Installation
This connector employs a clamp and solder assembly method, making it straightforward to mount onto RG58 coaxial cables. The secure locking mechanism and customizable cable length support flexibility for diverse setups, reducing installation errors and ensuring a robust mechanical and electrical connection.
Built for Endurance and Safety
With a flammability rating of UL94 V-0 for the PVC jacket and PTFE insulation, safety is prioritized in demanding environments. The corrosion-resistant metal body, gold-plated center contact, and rugged design provide long-term resistance to wear, ideal for frequent connect and disconnect operations.
FAQs of TNC Plug Male Straight 50 Rg58 Clamp For Cable:
Q: How do I install the TNC Plug Male Straight 50 RG58 Clamp on a coaxial cable?
A: To install the TNC Plug, strip the RG58 cable, then attach the connector using the clamp and solder method. Tighten the clamp securely to ensure good electrical contact, and solder the center conductor to the gold-plated contact for stable connectivity.Q: What are the typical applications for this TNC plug connector?
A: This connector is suitable for RF and coaxial cable connections in telecommunications, wireless communications, antennas, and test equipment, providing reliable signal transmission in various professional setups.Q: When should I use this connector over other types?
A: Opt for this TNC plug when you require a secure, threaded coupling for frequent connections and disconnections, high-frequency performance up to 11GHz, and robust resistance to corrosion, particularly with RG58 coaxial cables.Q: Where can the TNC Plug Male Straight 50 RG58 Clamp be used?
A: It is designed for indoor environments, as the connector is non-waterproof. Its ideal for laboratory setups, communication racks, broadcast sites, and any location where robust RF connections are needed without exposure to moisture.Q: What benefits does the gold-plated center contact provide?
A: The gold-plated center contact offers low contact resistance (1.5 m) and enhanced corrosion resistance, resulting in reliable signal integrity over the lifespan of the connector, even with frequent use.Q: How does the connector ensure safety during operation?
A: Safety is ensured through PTFE insulation, fire-resistant PVC rated to UL94 V-0, and a dielectric strength of 1500V RMS. The design supports voltages up to 500V RMS and operating temperatures from -40C to +85C.Price 55 INR/ Piece
- Minimum Order Quantity
- 5 Pieces
- Main Domestic Market
- All India
